Profile cutter, misc. cutters Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
124106 Solid carbide deburrer 60° PROTOTYP

VHM TAX Z
4
P M K N S
Ti-Ni

TAX coating
Application
For deburring and chamfering workpiece edges, also for contour work.
Order ID d1 l2 d2 l1 Angle Order ID d1 l2 d2 l1 Angle
mm mm mm mm mm mm mm mm
124106.0100 1 4.3 6 57 60° 124106.0200 1.5 7.35 10 100 60°
124108 Solid carbide deburrer 120° PROTOTYP
VHM TAX Z
4

P M K N S
Ti-Ni

TAX coating
Application
For deburring and chamfering workpiece edges, also for contour work.
Order ID d1 l2 d2 l1 Angle
mm mm mm mm
124108.0100 1.5 2.45 10 100 120°

124109 Solid carbide deburrer 90° FUTURO
VHM TiAIN Z
4
P M N S
≤ 600 ≤ 900 Cu, AI Ti-Ni
≤ 900
TiAIN coating
Application
For deburring and chamfering workpiece edges, also for contour work on stainless steel, titanium
and soft materials.
Order ID d2 l2 d1 l1 Angle
mm mm mm mm
124109.0100 3 1.1 0.8 40 90°
124109.0200 4 1.6 0.8 45 90°
124109.0300 6 2.5 1 50 90°
124109.0400 8 3.5 1 60 90°
124109.0500 10 4.5 1 70 90°
124109.0600 12 5.5 1 75 90°
124111 Solid carbide deburrer 90° FUTURO

VHM TiAIN Z
2-6
P M K

Type N, TiALN, HA, from 6mm on HB, DIN 6527 long.
Application
For deburring and chamfering workpiece edges, also for contour work on steel materials up to
53HRc.
Order ID d1 l2 d2 l1 Angle Z Shank
mm mm mm mm
124111.0100 1 0.5 3 38 90° 2 HA
124111.0200 2 1 3 38 90° 3 HA
124111.0300 3 1.5 3 38 90° 4 HA
124111.0400 4 2 4 54 90° 4 HA
124111.0500 6 3 6 57 90° 4 HB
124111.0600 8 4 8 63 90° 5 HB
124111.0700 10 5 10 72 90° 6 HB
124111.0800 12 6 12 83 90° 6 HB
124111.0900 16 8 16 92 90° 6 HB
124111.1000 20 10 20 104 90° 6 HB

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 547
