124125 Solid carbide rounding end mill PROTOTYP

VHM TAX Z
4
P M K N S
≤ 900 Ti-Ni
≤ 900
Corner rounding profile cutter, concave, with TAX coating.
Order ID d1 R d2 l1 Order ID d1 R d2 l1
mm mm mm mm mm mm mm mm
124125.0100 4 1 8 63 124125.0500 5 3 12 83
124125.0200 4 1.5 8 63 124125.0600 6 4 14 83
124125.0300 5 2 10 72 124125.0700 6 5 16 92
124125.0400 5 2.5 10 72 124125.0800 8 6 20 104
124127 Solid carbide ball nose end mill FUTURO
VHM TiAIN Z
4

P M K N S
≤ 900 AI Ti-Ni

Type N, TiALN, HA, works standard
Application
For milling radii on workpieces. Universally applicable up to 53 HRC.
Order ID r d1 l1 d2 Order ID r d1 l1 d2
mm mm mm mm mm mm mm mm
124127.0100 0.2 5.6 58 6 124127.0900 3 6 75 12
124127.0200 0.3 5.4 58 6 124127.1000 3.5 9 80 16
124127.0300 0.4 5.2 58 6 124127.1100 4 8 80 16
124127.0400 0.5 7 70 8 124127.1200 4.5 7 80 16
124127.0500 1 6 70 8 124127.1300 5 10 80 20
124127.0600 1.5 7 75 10 124127.1400 6 8 80 20
124127.0700 2 6 75 10 124127.1500 8 9 100 25
124127.0800 2.5 7 75 12 124127.1600 10 5 100 25
124250 Solid carbide engraver‘s cutter FUTURO
VHM

P M K N S
≤ 850 ≤ 900 Ti

Application
For general purpose use.
Tolerance d2: h6
Order ID d2 r l1 Alpha
mm mm mm
124250.0200 3 0.1 33 30°
124250.0300 3 0.2 33 30°

124252 Solid carbide engraver‘s cutter FUTURO
VHM TiAIN

P M K N S
≤ 850 Ti

TiAIN coating
Application
Especially well suited to fine engraving in stainless steel.
Tolerance d2: h6
Order ID d2 r l1 Alpha
mm mm mm
124252.0100 3 0.1 33 30°
124252.0200 3 0.2 33 30°
