Profile cutter, misc. cutters Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
118000 Side and face milling cutter

HSS-E Z
Co5 12-22
P M K N S
Ti-Ni

Type N, HSSE-Co5, staggered-tooth, to DIN 885A.
Order ID d1 b d2 d3 Z Order ID d1 b d2 d3 Z
mm mm mm mm mm mm mm mm
118000.0100 50 7 16 26 12 118000.2500 100 6 32 48 18
118000.0200 50 8 16 26 12 118000.2600 100 7 32 48 18
118000.0400 50 10 16 26 12 118000.2700 100 8 32 48 18
118000.0600 63 6 22 34 14 118000.2800 100 10 32 48 18
118000.0700 63 7 22 34 14 118000.2900 100 12 32 48 18
118000.0800 63 8 22 34 14 118000.3000 100 14 32 48 18
118000.1000 63 10 22 34 14 118000.3700 125 10 32 48 20
118000.1100 63 12 22 34 12 118000.3800 125 12 32 48 20
118000.1500 80 6 27 40 18 118000.4700 160 10 40 58 22
118000.1700 80 8 27 40 18 118000.4800 160 12 40 58 22
118000.1900 80 10 27 40 18 118000.4900 160 14 40 58 22
118000.2000 80 12 27 40 18
118020 Side milling cutter
HSS-E Z
Co5 18-36

P M K N S
Ti-Ni

Type N, HSSE-Co5, staggered-tooth, slim version, DIN 1834A.
Order ID d1 b d2 d3 Z Order ID d1 b d2 d3 Z
mm mm mm mm mm mm mm mm
118020.0100 50 1.5 16 26 18 118020.2700 80 6 27 41 24
118020.0200 50 1.6 16 26 18 118020.2900 100 1.5 32 48 28
118020.0300 50 2 16 26 18 118020.3000 100 1.6 32 48 28
118020.0400 50 2.5 16 26 18 118020.3100 100 2 32 48 28
118020.0500 50 3 16 26 18 118020.3200 100 2.5 32 48 28
118020.0700 50 4 16 26 18 118020.3300 100 3 32 48 28
118020.0800 50 5 16 26 18 118020.3500 100 4 32 48 28
118020.0900 50 6 16 26 18 118020.3600 100 5 32 48 28
118020.1000 63 1.5 22 34 22 118020.3700 100 6 32 48 28
118020.1100 63 1.6 22 34 22 118020.4000 125 1.6 32 48 32
118020.1200 63 2 22 34 22 118020.4100 125 2 32 48 32
118020.1300 63 2.5 22 34 22 118020.4200 125 2.5 32 48 32
118020.1400 63 3 22 34 22 118020.4300 125 3 32 48 32
118020.1600 63 4 22 34 22 118020.4500 125 4 32 48 32
118020.1700 63 5 22 34 22 118020.4600 125 5 32 48 32
118020.1800 63 6 22 34 22 118020.4700 125 6 32 48 32
118020.1900 80 1.5 27 41 24 118020.5200 160 2 40 65 36
118020.2000 80 1.6 27 41 24 118020.5300 160 2.5 40 65 36
118020.2100 80 2 27 41 24 118020.5400 160 3 40 65 36
118020.2200 80 2.5 27 41 24 118020.5600 160 4 40 65 36
118020.2300 80 3 27 41 24 118020.5700 160 5 40 60 36
118020.2500 80 4 27 41 24 118020.5800 160 6 40 60 36
118020.2600 80 5 27 41 24
118040 Side milling cutter
HSS-E TiN Z
Co5 22-32

P M K N S
Ti-Ni

Type N, TiN, HSSE-Co5, staggered-tooth, slim version, DIN 1834A.
Order ID d1 b d2 d3 Z Order ID d1 b d2 d3 Z
mm mm mm mm mm mm mm mm
118040.0100 63 2 22 34 22 118040.0800 100 3 32 48 28
118040.0200 63 3 22 34 22 118040.0900 100 4 32 48 28
118040.0300 63 4 22 34 22 118040.1000 125 2 32 48 32
118040.0400 80 2 27 41 24 118040.1100 125 3 32 48 32
118040.0500 80 3 27 41 24 118040.1200 125 4 32 48 32
118040.0600 80 4 27 41 24 118040.1300 125 5 32 48 32
118040.0700 100 2 32 48 28
