Profile cutter, misc. cutters Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
113480 Roughing shell end mill FRANKEN

HSS-E TiCN λ: 25º Z
CoPM γ: 14º 7-12
P M K N S
≤ 850 ≤ 900 Cu Ti

4051C, Type NR-Topline, HSS-E Co PM, TiCN, angle of twist 25°, roughing profile, bore with key-
way and drive slot, DIN 1880.
Tolerance d1: js14
Order ID d1 b1 d2 Z Order ID d1 b1 d2 Z
mm mm mm mm mm mm
113480.0100 40 32 16 7 113480.0400 80 45 27 10
113480.0200 50 36 22 8 113480.0500 100 50 32 12
113480.0300 63 40 27 8
113500 Roughing shell end mill FRANKEN
HSS-E λ: 25º Z
Co5 γ: 14º 7-12

P M K N S
≤ 850 ≤ 900 Cu Ti

4050, Type NR, HSSE-Co5, angle of twist 25°, roughing profile, bore with keyway and drive slot,
DIN 1880.
Tolerance d1: js14
Order ID d1 b1 d2 Z Order ID d1 b1 d2 Z
mm mm mm mm mm mm
113500.0100 40 32 16 7 113500.0400 80 45 27 10
113500.0200 50 36 22 8 113500.0500 100 50 32 12
113500.0300 63 40 27 8
113520 Roughing shell end mill FRANKEN
HSS-E TiCN λ: 25º Z
Co5 γ: 14º 7-12
P M K N S
≤ 850 ≤ 900 Cu Ti

4050C, Type NR, HSSE-Co5, angle of twist 25°, roughing profile, bore with keyway and drive slot,
DIN 1880.
Tolerance d1: js14
Order ID d1 b1 d2 Z Order ID d1 b1 d2 Z
mm mm mm mm mm mm
113520.0100 40 32 16 7 113520.0400 80 45 27 10
113520.0200 50 36 22 8 113520.0500 100 50 32 12
113520.0300 63 40 27 8
