1 27875 Solid carbide end mill FUTURO

VHM TiAIN λ: 35/38º Z
4
P M K
≤ 850 ≤ 900 HPC

HPC, TiAlN, 35°/38° helix angle, long, HB, tapered neck with protective chamfer, with Weldon
flat, centre cutting, works standard.
Application
For machining alloyed and unalloyed steels up to 1200 N/mm², tool steels and cast materials.
Tolerances: d1: h10 / d2: h6
Order ID d1 l2 l3 d2 l1 d3 Protective chamfer
mm mm mm mm mm mm mm
127875.0100 6 13 21 6 57 5.8 0.2
127875.0200 8 19 27 8 63 7.6 0.2
127875.0300 10 22 32 10 72 9.5 0.2
127875.0400 12 26 38 12 83 11.5 0.3
127875.0500 16 32 44 16 92 15.5 0.3
127875.0600 20 38 54 20 104 19.5 0.4

1 27870 Solid carbide end mill FUTURO
VHM TiAIN λ: 35/38º Z
4

P M K
≤ 850 ≤ 900 HPC

HPC, TiAlN, 35°/38° helix angle, long, with protective chamfer, with Weldon flat, centre cutting,
works standard.
Application
For machining alloyed and unalloyed steels up to 1200 N/mm², tool steels and cast materials.
Tolerances: d1: h10 / d2: h6
Order ID d1 l2 d2 l1 Protective chamfer
mm mm mm mm mm
127870.0100 6 13 6 57 0.2
127870.0200 8 19 8 63 0.2
127870.0300 10 22 10 72 0.2
127870.0400 12 26 12 83 0.3
127870.0500 16 32 16 92 0.3
127870.0600 20 38 20 104 0.4
1 27865 Solid carbide end mill FUTURO
VHM TiAIN λ: 35/38º Z
4

P M K HPC
≤ 850 ≤ 900

HPC, TiAlN, 35°/38° helix angle, short, with protective chamfer, with Weldon flat, centre cutting,
works standard.
Application
For machining alloyed and unalloyed steels up to 1200 N/mm², tool steels and cast materials.
Tolerances: d1: h10 / d2: h6
Order ID d1 l2 d2 l1 Protective chamfer
mm mm mm mm mm
127865.0100 6 10 6 54 0.2
127865.0200 8 12 8 58 0.2
127865.0300 10 14 10 66 0.2
127865.0400 12 16 12 73 0.3
127865.0500 16 22 16 82 0.3
127865.0600 20 26 20 92 0.4
