113401 Finishing shell end mill FRANKEN

HSS-E λ: 25º Z
8-14
P M K N
≤ 850 ≤ 900 Cu

4010, Type N, HSS-E, angle of twist 25°, bore with keyway and drive slot, DIN 1880.
Tolerance d1: k10
Order ID d1 b1 d2 Z Order ID d1 b1 d2 Z
mm mm mm mm mm mm
113401.0100 40 32 16 8 113401.0400 80 45 27 10
113401.0200 50 36 22 8 113401.0500 100 50 32 12
113401.0300 63 40 27 8 113401.0600 125 56 40 14
113402 Finishing shell end mill FRANKEN
HSS-E TiCN λ: 25º Z
8-14

P M K N S
≤ 850 ≤ 900 Cu Ti

4010C, Type N, HSS-E, TiCN, angle of twist 25°, bore with keyway and drive slot, DIN 1880.
Tolerance d1: k10
Order ID d1 b1 d2 Z Order ID d1 b1 d2 Z
mm mm mm mm mm mm
113402.0100 40 32 16 8 113402.0400 80 45 27 10
113402.0200 50 36 22 8 113402.0500 100 50 32 12
113402.0300 63 40 27 8 113402.0600 125 56 40 14
113440 Shell end mill for aluminium FRANKEN
HSS-E λ: 30º Z
Co5 γ: 24º 6
N
Cu
AI≤4%Si
4040, Type W, for aluminium, HSSE-Co5, angle of twist 30°, bore with keyway and drive slot, DIN
1880.
Tolerance d1: k10
Order ID d1 b1 d2 Order ID d1 b1 d2
mm mm mm mm mm mm
113440.0100 40 32 16 113440.0400 80 45 27
113440.0200 50 36 22 113440.0500 100 50 32
113440.0300 63 40 27
113460 Roughing shell end mill FRANKEN

HSS-E λ: 25º Z
CoPM γ: 14º 7-12
P M K N S
≤ 850 ≤ 900 Cu Ti

4051, Type NR-Topline, HSS-E Co PM, angle of twist 25°, roughing profile, bore with keyway and
drive slot, DIN 1880.
Tolerance d1: js14
Order ID d1 b1 d2 Z Order ID d1 b1 d2 Z
mm mm mm mm mm mm
113460.0100 40 32 16 7 113460.0400 80 45 27 10
113460.0200 50 36 22 8 113460.0500 100 50 32 12
113460.0300 63 40 27 8
