Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 27890 Solid carbide end mill FUTURO

VHM AlTiN λ: 35/38º Z
4
M S
≤ 900 Ti-Ni HPC
≤ 900
HPC, AlTiN, INOX, 35°/38° helix angle, long, with protective chamfer, with Weldon flat, centre
cutting, works standard.
Application
For work on stainless steels, titanium and super alloys up to 1200 N/mm².
Tolerances: d1: h10 / d2: h6
Order ID d1 l2 d2 l1 Protective chamfer
mm mm mm mm mm
127890.0100 6 13 6 57 0.2
127890.0200 8 19 8 63 0.2
127890.0300 10 22 10 72 0.2
127890.0400 12 26 12 83 0.3
127890.0500 16 32 16 92 0.3
127890.0600 20 38 20 104 0.4
1 27885 Solid carbide end mill FUTURO
VHM AlTiN λ: 35/38º Z
4

M S
≤ 900 Ti-Ni HPC
≤ 900
HPC, AlTiN, INOX, 35°/38° helix angle, short, with protective chamfer, with Weldon flat, centre
cutting, works standard.
Application
For work on stainless steels, titanium and super alloys up to 1200 N/mm².
Tolerances: d1: h10 / d2: h6
Order ID d1 l2 d2 l1 Protective chamfer
mm mm mm mm mm
127885.0100 6 10 6 54 0.2
127885.0200 8 12 8 58 0.2
127885.0300 10 14 10 66 0.2
127885.0400 12 16 12 73 0.3
127885.0500 16 22 16 82 0.3
127885.0600 20 26 20 92 0.4
1 27880 Solid carbide end mill FUTURO
VHM TiAIN λ: 35/38º Z
4
P M K HPC
≤ 850 ≤ 900

HPC, TiAlN, 35°/38° helix angle, extra long, with protective chamfer, with Weldon flat, centre
cutting, works standard.
Application
For machining alloyed and unalloyed steels up to 1200 N/mm², tool steels and cast materials.
Tolerances: d1: h10 / d2: h6
Order ID d1 l2 d2 l1 Protective chamfer
mm mm mm mm mm
127880.0100 6 22 6 63 0.2
127880.0200 8 28 8 80 0.2
127880.0300 10 33 10 100 0.2
127880.0400 12 42 12 100 0.3
127880.0500 16 53 16 150 0.3
127880.0600 20 68 20 150 0.4

534 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
