126120 Solid carbide finishing end mill FUTURO X-CUT

VHM TiAIN λ: 30º Z
γ: 9º 4
P K H

Type N, X.Treme, sizes 3 mm and greater with clamping flat, angle of twist 30°, centre cut, short,
works standard.
Application
For use on materials up to 65 HRC.
Tolerance d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
126120.0100 2 6 4 40 126120.1200 7.5 16 8 60
126120.0200 2.5 8 4 40 126120.1300 8 19 8 60
126120.0300 3 8 6 45 126120.1500 9 19 10 70
126120.0400 3.5 10 6 45 126120.1700 10 22 10 70
126120.0500 4 11 6 45 126120.1900 11 22 12 75
126120.0600 4.5 11 6 45 126120.2100 12 26 12 75
126120.0700 5 13 6 50 126120.2200 14 26 14 85
126120.0800 5.5 13 6 50 126120.2300 16 32 16 100
126120.0900 6 13 6 50 126120.2400 20 38 20 105
126120.1000 6.5 16 8 60 126120.2500 25 45 25 120
126120.1100 7 16 8 60
126140 Solid carbide finishing end mill FUTURO X-CUT
VHM TiAIN λ: 30º Z
γ: 3º 4
P K H

Type N, X.Treme, with flat, angle of twist 30°, centre cut, long, works standard.
Application
For use on materials up to 65 HRC.
Tolerance d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
126140.0100 3 12 6 50 126140.0600 10 30 10 90
126140.0200 4 15 6 50 126140.0700 12 30 12 90
126140.0300 5 20 6 60 126140.0800 16 50 16 110
126140.0400 6 20 6 60 126140.0900 20 55 20 110
126140.0500 8 25 8 70 126140.1000 25 75 25 140
126160 Solid carbide finishing end mill FUTURO X-CUT
VHM TiAIN λ: 30º Z
γ: 2º 4

P K H

Type N, X.Treme, without flat, angle of twist 30°, with flanging radius on face, centre cut, short,
works standard.
Application
For use on materials up to 65 HRC.
Tolerance d2: h6
Order ID d1 r l2 l3 d2 l1 d3
mm mm mm mm mm mm mm
126160.0100 2 0.2 2.5 5 6 50 1.9
126160.0200 2.5 0.25 3 6 6 50 2.4
126160.0300 3 0.3 4 7 6 50 2.8
126160.0400 3.5 0.35 4.5 8 6 50 3.2
126160.0500 4 0.4 5 9 6 50 3.7
126160.0600 5 0.5 6 12 6 50 4.6
126160.0700 6 0.6 7 14 6 55 5.6
126160.0800 8 0.8 10 18 8 60 7.4
126160.0900 10 1.0 12 25 10 70 9.4
126160.1000 12 1.2 15 30 12 80 11.4
126160.1100 16 1.6 18 35 16 90 15.4
