Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 25740 Solid carbide high-performance end mill FUTURO A-CUT

VHM ZrN λ: 45º Z
γ: 14º 3
N

HPC ALU, ZrN, angle of twist 45°, short, with protective chamfer, tapered neck, centre-cutting,
works standard.
Application
High-performance end mill for machining aluminium alloys, copper, copper alloys and other non-
ferrous metals.
Tolerances: d1: h10 / d2: h6
Order ID d1 l2 l3 d2 l1 d3 Protective chamfer
mm mm mm mm mm mm mm
125740.0100 3 8 11 6 57 2.8 0.1
125740.0200 4 11 17 6 57 3.8 0.1
125740.0300 5 13 17 6 57 4.8 0.1
125740.0400 6 13 17 6 57 5.8 0.2
125740.0500 6 13 41 6 80 5.8 0.2
125740.0600 8 21 24 8 63 7.8 0.2
125740.0700 8 21 61 8 100 7.8 0.2
125740.0800 10 22 29 10 72 9.7 0.2
125740.0900 10 22 57 10 100 9.7 0.2
125740.1000 12 26 35 12 83 11.7 0.2
125740.1100 12 26 72 12 120 11.7 0.2
125740.1200 16 36 41 16 92 15.7 0.2
125740.1300 16 36 99 16 150 15.7 0.2
125740.1400 18 36 41 18 92 17.6 0.2
125740.1500 18 36 99 18 150 17.6 0.2
125740.1600 20 41 51 20 104 19.5 0.2
125740.1700 20 41 97 20 150 19.5 0.2
125740.1800 25 50 64 25 125 24.5 0.3
1 25750 Solid carbide high-performance end mill FUTURO A-CUT
VHM ZrN λ: 45º Z
γ: 14º 3
N

HPC ALU, ZrN, angle of twist 45°, short, with corner radius, tapered neck, with Weldon flat,
centre-cutting, works standard.
Application
High-performance end mill for machining aluminium, aluminium alloys, copper, copper alloys and
other non-ferrous metals.
Tolerances: d1: h10 / d2: h6
Order ID d1 r l2 l3 d2 l1 Order ID d1 r l2 l3 d2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
125750.0100 5 1 13 17 6 57 125750.0800 12 0.5 26 35 12 83
125750.0200 6 0.5 13 17 6 57 125750.0900 12 1 26 35 12 83
125750.0300 6 1 13 17 6 57 125750.1000 16 2 36 41 16 92
125750.0400 8 0.5 21 24 8 63 125750.1100 16 4 36 41 16 92
125750.0500 8 1 21 24 8 63 125750.1200 20 4 41 51 20 104
125750.0600 10 0.5 22 29 10 72 125750.1300 25 5 50 64 25 125
125750.0700 10 1 22 29 10 72
