Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
126060 Solid carbide finishing end mill FUTURO X-CUT

VHM TiAIN λ: 45º Z
γ: -3º 6
P K H

Type N, X.Treme, without Weldon flat, angle of twist 45°, flanging radius on face, works standard.
Application
For use on materials up to 65 HRC.
Tolerance d2: h6
Order ID d1 r l2 l3 d2 l1 d3
mm mm mm mm mm mm mm
126060.0100 6 0.5 6 14 6 50 5.7
126060.0200 8 0.5 8 24 8 60 7.65
126060.0300 10 1 10 30 10 70 9.65
126060.0400 12 1 12 30 12 75 11.6
126080 Solid carbide finishing end mill FUTURO X-CUT
VHM TiAIN λ: 45º Z
γ: -3º 6
P K H

Type N, X.Treme, without flat, angle of twist 45°, centre cut, works standard, extra long.
Application
For use on materials up to 65 HRC.
Tolerance d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
126080.0100 6 26 6 70 126080.0400 12 56 12 110
126080.0200 8 36 8 90 126080.0500 16 66 16 130
126080.0300 10 46 10 100 126080.0600 20 76 20 140
126100 Solid carbide finishing end mill FUTURO X-CUT
VHM TiAIN λ: 45º Z
γ: -8º 6
P K H

Type N, X.Treme, without flat, angle of twist 45°, with flanging radius on face, centre cut, works
standard, long.
Application
For use on materials up to 65 HRC.
Tolerance d2: h6
Order ID d1 r l2 d2 l1 Order ID d1 r l2 d2 l1
mm mm mm mm mm mm mm mm mm mm
126100.0100 6 0.5 13 6 70 126100.0600 12 1 26 12 110
126100.0200 8 0.5 19 8 90 126100.0700 16 1 32 16 130
126100.0300 10 0.5 22 10 100 126100.0900 20 1 38 20 140
126100.0400 10 1 22 10 100

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 509
