P. 521
Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 26320 Solid carbide economy end mill FUTURO X-CUT
VHM TiAIN λ: 30º Z
γ: 8º 3
P K H
Type N, X.Treme, without flat, angle of twist 30°, centre cut, works standard.
Application
For use on materials up to 65 HRC.
Tolerance d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
126320.0100 1 2 4 35 126320.0700 8 11 8 43
126320.0200 2 4 4 35 126320.0800 10 13 10 50
126320.0300 3 5 6 36 126320.0900 12 15 12 55
126320.0400 4 7 6 38 126320.1000 14 15 14 58
126320.0500 5 8 6 39 126320.1100 16 18 16 62
126320.0600 6 8 6 39
1 26420 Solid carbide slot cutter FUTURO X-CUT
VHM TiAIN λ: 38º Z
γ: 6º 3
P K H
Type N, X.Treme, without flat, angle of twist 38°, 1 tooth over centre, works standard.
Application
For use on materials up to 65 HRC.
Tolerance d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
126420.0100 3 10 6 50 126420.0600 10 22 10 72
126420.0200 4 12 6 50 126420.0700 12 25 12 73
126420.0300 5 14 6 57 126420.0800 16 32 16 82
126420.0400 6 16 6 57 126420.0900 20 38 20 92
126420.0500 8 20 8 63
1 26440 Solid carbide slot cutter FUTURO X-CUT
VHM TiAIN λ: 30º Z
γ: 6º 2
P K H
Type N, X.Treme, sizes 3 mm and greater with Weldon flat, angle of twist 30°, centre cut, works
standard.
Application
For use on materials up to 65 HRC.
Tolerance d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm
126440.0100 1 2.5 4 40 126440.1200 6.5 16 8 60
126440.0200 1.5 4 4 40 126440.1300 7 16 8 60
126440.0300 2 6 4 40 126440.1400 7.5 16 8 60
126440.0400 2.5 8 4 40 126440.1500 8 19 8 60
126440.0500 3 8 6 45 126440.1600 8.5 19 10 70
126440.0600 3.5 10 6 45 126440.1700 9 19 10 70
126440.0700 4 11 6 45 126440.1800 9.5 19 10 70
126440.0800 4.5 11 6 45 126440.1900 10 22 10 70
126440.0900 5 13 6 50 126440.2100 11 22 12 75
126440.1000 5.5 13 6 50 126440.2300 12 26 12 75
126440.1100 6 13 6 50
512 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
