Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
125734 Solid carbide high-performance end mill FUTURO S-CUT

VHM TiAIN λ: 35/38º Z
γ: 6º 4
P M K S
≤ 900 Ti-Ni
≤ 900
HPC, TiAlN, angle of twist 35°/38°, long, HB, with corner radius, with Weldon flat, centre-cut-
ting, works standard.
Application
High-performance end mill for machining alloyed and unalloyed steels up to 1600 N/mm2, tool
steels and cast materials.
Tolerances: d1: h10 / d2: h6
Order ID d1 r l2 d2 l1 Order ID d1 r l2 d2 l1 Order ID d1 r l2 d2 l1
mm mm mm mm mm mm mm mm mm mm mm mm mm mm mm
125734.0050 3 0.25 8 6 57 125734.1200 8 1 19 8 63 125734.2500 16 1 32 16 92
125734.0100 4 0.25 11 6 57 125734.1300 8 1.5 19 8 63 125734.2600 16 1.5 32 16 92
125734.0200 4 0.5 11 6 57 125734.1400 8 2 19 8 63 125734.2700 16 2 32 16 92
125734.0300 4 1 11 6 57 125734.1500 10 0.5 22 10 72 125734.2800 16 2.5 32 16 92
125734.0400 5 0.5 13 6 57 125734.1600 10 1 22 10 72 125734.2900 18 1.5 32 18 92
125734.0500 5 1 13 6 57 125734.1700 10 1.5 22 10 72 125734.3000 18 2.5 32 18 92
125734.0600 5 1.5 13 6 57 125734.1800 10 2 22 10 72 125734.3100 20 1 38 20 104
125734.0700 6 0.5 13 6 57 125734.1900 12 0.5 26 12 83 125734.3200 20 1.5 38 20 104
125734.0800 6 1 13 6 57 125734.2000 12 1 26 12 83 125734.3300 20 2 38 20 104
125734.0900 6 1.5 13 6 57 125734.2100 12 1.5 26 12 83 125734.3400 20 2.5 38 20 104
125734.2300 14 1 26 14 83 125734.2200 12 2 26 12 83 125734.3500 20 3 38 20 104
125734.1000 6 2 13 6 57 125734.2400 14 2 26 14 83 125734.3600 20 4 38 20 104
125734.1100 8 0.5 19 8 63 125734.2450 16 0.5 32 16 92 125734.3700 20 5 38 20 104
125737 Solid carbide high-performance end mill FUTURO S-CUT
VHM AlTiN λ: 35/38º Z
γ: 10º 4
P M N S INOX, TITAN, INCONEL
≤ 850 Cu Ti-Ni

HPC INOX, AlTiN, angle of twist 35°/38°, short, with protective chamfer, with Weldon flat, centre-
cutting, DIN6527L.
Application
High-performance end mill for machining stainless steels, titanium and Inconel up to 1600 N/
mm2.
Tolerances: d1: h10 / d2: h6
Order ID d1 l2 d2 l1 Protective chamfer
mm mm mm mm mm
125737.0100 3 6 6 54 0.1
125737.0200 4 8 6 54 0.13
125737.0300 5 9 6 54 0.18
125737.0400 6 10 6 54 0.2
125737.0500 7 12 8 58 0.2
125737.0600 8 12 8 58 0.2
125737.0700 9 14 10 66 0.3
125737.0800 10 14 10 66 0.3
125737.0900 11 16 12 73 0.3
125737.1000 12 16 12 73 0.3
125737.1100 13 18 14 75 0.3
125737.1200 14 18 14 75 0.3
125737.1300 16 22 16 82 0.4
125737.1400 18 24 18 84 0.4
125737.1500 20 26 20 92 0.5

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 503
