Page 509 - Benma | Blue book 5.0

Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 25065 Solid carbide high-performance end mill FUTURO

VHM AlTiN λ: 37º Z
γ: 6º 4
P M K S HPC
Ti-Ni

Type HPC, top-quality carbide, AlTiN, without flat, uneven twist, works standard.
Application
For machining stainless steels, tool steels, alloyed and unalloyed steels, titanium, Inconel and pre-
hardened steels up to 42 HRC. Extremely wear-resistant, creates outstanding surfaces and reduces
vibrations to a minimum.
Tolerances: d1: 0 / -0.03 mm; d2: h6
Order ID d1 l2 l3 d2 l1 d3 Order ID d1 l2 l3 d2 l1 d3
mm mm mm mm mm mm mm mm mm mm mm mm
125065.0100 3 7 12 6 54 2.7 125065.1300 10 14 25 10 72 9.2
125065.0200 3 7 17 6 57 2.7 125065.1400 10 14 35 10 82 9.2
125065.0300 4 8 15 6 57 3.7 125065.1500 10 14 55 10 102 9.2
125065.0400 4 8 22 6 63 3.7 125065.1600 12 16 30 12 83 11
125065.0500 5 10 17 6 57 4.7 125065.1700 12 16 40 12 93 11
125065.0600 5 10 27 6 67 4.7 125065.1800 12 16 64 12 117 11
125065.0700 6 10 15 6 57 5.5 125065.1900 16 22 38 16 92 15
125065.0800 6 10 20 6 62 5.5 125065.2000 16 22 55 16 109 15
125065.0900 6 10 32 6 74 5.5 125065.2100 16 22 87 16 141 15
125065.1000 8 12 20 8 63 7.5 125065.2200 20 26 50 20 104 19
125065.1100 8 12 30 8 73 7.5 125065.2300 20 26 70 20 124 19
125065.1200 8 12 46 8 90 7.5 125065.2400 20 26 110 20 164 19
1 25320 Solid carbide high-performance end mill FUTURO S-CUT
VHM AlTiN λ: 52º Z
γ: -5º 3-4
P M K N S H
≤ 900 Cu Ti

HPC, AlTiN, angle of twist 52°, long, HB, with Weldon flat, centre-cutting, works standard. Enlar-
ged flute with protective corner radius.
Application
High-performance end mill for machining alloyed and unalloyed steels, tool steels, and hard ma-
terials up to 65 HRC.
Tolerances: d1: h10 ; d2: h6
Order ID d1 r l2 l3 d2 l1 d3 Z Order ID d1 r l2 l3 d2 l1 d3 Z
mm mm mm mm mm mm mm mm mm mm mm mm mm mm
125320.0100 3 0.2 8 17 6 57 2.9 3 125320.1900 10 1 22 31 10 72 9.8 4
125320.0200 3 0.5 8 17 6 57 2.9 3 125320.2000 10 1.5 22 31 10 72 9.8 4
125320.0300 4 0.3 11 20 6 57 3.8 4 125320.2100 10 2 22 31 10 72 9.8 4
125320.0400 4 0.5 11 20 6 57 3.8 4 125320.2200 12 0.5 26 37 12 83 11.8 4
125320.0500 4 1 11 20 6 57 3.8 4 125320.2300 12 1 26 37 12 83 11.8 4
125320.0600 5 0.3 13 20 6 57 4.8 4 125320.2400 12 1.5 26 37 12 83 11.8 4
125320.0700 5 0.5 13 20 6 57 4.8 4 125320.2500 12 2 26 37 12 83 11.8 4
125320.0800 5 1 13 20 6 57 4.8 4 125320.2600 16 0.5 32 43 16 92 15.8 4
125320.0900 6 0.3 13 20 6 57 5.8 4 125320.2700 16 1 32 43 16 92 15.8 4
125320.1000 6 0.5 13 20 6 57 5.8 4 125320.2800 16 1.5 32 43 16 92 15.8 4
125320.1100 6 1 13 20 6 57 5.8 4 125320.2900 16 2 32 43 16 92 15.8 4
125320.1200 6 1.5 13 20 6 57 5.8 4 125320.3000 16 1 32 43 16 150 15.8 4
125320.1300 6 2 13 20 6 57 5.8 4 125320.3100 20 0.5 38 53 20 92 19.8 4
125320.1400 8 0.5 19 26 8 63 7.8 4 125320.3200 20 1 38 53 20 92 19.8 4
125320.1500 8 1 19 26 8 63 7.8 4 125320.3300 20 1.5 38 53 20 92 19.8 4
125320.1600 8 1.5 19 26 8 63 7.8 4 125320.3400 20 2 38 53 20 92 19.8 4
125320.1700 8 2 19 26 8 63 7.8 4 125320.3500 20 1 38 53 20 150 19.8 4
125320.1800 10 0.5 22 31 10 72 9.8 4 125320.3600 25 2 38 53 25 160 24.8 4
