Solid carbide milling / PKD milling Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
126605 Solid carbide micro end mill FUTURO

VHM TiAIN λ: 30º Z
γ: 8º 3
P M N S
≤ 850 ≤ 900 Ti

TiAlN, centre cut, angle of twist 30°.
Tolerances: d1: +/-0.01; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
126605.0100 0.30 0.30 3 38 126605.2000 1.25 1.25 3 38 126605.3900 2.20 2.20 3 38
126605.0200 0.35 0.35 3 38 126605.2100 1.30 1.30 3 38 126605.4000 2.25 2.25 3 38
126605.0300 0.40 0.40 3 38 126605.2200 1.35 1.35 3 38 126605.4100 2.30 2.30 3 38
126605.0400 0.45 0.45 3 38 126605.2300 1.40 1.40 3 38 126605.4200 2.35 2.35 3 38
126605.0500 0.50 0.50 3 38 126605.2400 1.45 1.45 3 38 126605.4300 2.40 2.40 3 38
126605.0600 0.55 0.55 3 38 126605.2500 1.50 1.50 3 38 126605.4400 2.45 2.45 3 38
126605.0700 0.60 0.60 3 38 126605.2600 1.55 1.55 3 38 126605.4500 2.50 2.50 3 38
126605.0800 0.65 0.65 3 38 126605.2700 1.60 1.60 3 38 126605.4600 2.55 2.55 3 38
126605.0900 0.70 0.70 3 38 126605.2800 1.65 1.65 3 38 126605.4700 2.60 2.60 3 38
126605.1000 0.75 0.75 3 38 126605.2900 1.70 1.70 3 38 126605.4800 2.65 2.65 3 38
126605.1100 0.80 0.80 3 38 126605.3000 1.75 1.75 3 38 126605.4900 2.70 2.70 3 38
126605.1200 0.85 0.85 3 38 126605.3100 1.80 1.80 3 38 126605.5000 2.75 2.75 3 38
126605.1300 0.90 0.90 3 38 126605.3200 1.85 1.85 3 38 126605.5100 2.80 2.80 3 38
126605.1400 0.95 0.95 3 38 126605.3300 1.90 1.90 3 38 126605.5200 2.85 2.85 3 38
126605.1500 1.00 1.00 3 38 126605.3400 1.95 1.95 3 38 126605.5300 2.90 2.90 3 38
126605.1600 1.05 1.05 3 38 126605.3500 2.00 2.00 3 38 126605.5400 2.95 2.95 3 38
126605.1700 1.10 1.10 3 38 126605.3600 2.05 2.05 3 38 126605.5500 3.00 3.00 3 38
126605.1800 1.15 1.15 3 38 126605.3700 2.10 2.10 3 38
126605.1900 1.20 1.20 3 38 126605.3800 2.15 2.15 3 38
126610 Solid carbide micro end mill FUTURO
VHM TiAIN λ: 30º Z
γ: 8º 3
P M N S
≤ 850 ≤ 900 Ti

TiAlN, centre cut, angle of twist 30°.
Tolerances: d1: +/-0.01; d2: h6
Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1 Order ID d1 l2 d2 l1
mm mm mm mm mm mm mm mm mm mm mm mm
126610.0100 0.50 1.5 3 38 126610.1800 1.35 4.05 3 38 126610.3500 2.20 6.6 3 38
126610.0200 0.55 1.65 3 38 126610.1900 1.40 4.2 3 38 126610.3600 2.25 6.75 3 38
126610.0300 0.60 1.8 3 38 126610.2000 1.45 4.35 3 38 126610.3700 2.30 6.9 3 38
126610.0400 0.65 1.95 3 38 126610.2100 1.50 4.5 3 38 126610.3800 2.35 7.05 3 38
126610.0500 0.70 2.1 3 38 126610.2200 1.55 4.65 3 38 126610.3900 2.40 7.2 3 38
126610.0600 0.75 2.25 3 38 126610.2300 1.60 4.8 3 38 126610.4000 2.45 7.35 3 38
126610.0700 0.80 2.4 3 38 126610.2400 1.65 4.95 3 38 126610.4100 2.50 7.5 3 38
126610.0800 0.85 2.55 3 38 126610.2500 1.70 5.1 3 38 126610.4200 2.55 7.65 3 38
126610.0900 0.90 2.7 3 38 126610.2600 1.75 5.25 3 38 126610.4300 2.60 7.8 3 38
126610.1000 0.95 2.85 3 38 126610.2700 1.80 5.4 3 38 126610.4400 2.65 7.95 3 38
126610.1100 1.00 3 3 38 126610.2800 1.85 5.55 3 38 126610.4500 2.70 8.1 3 38
126610.1200 1.05 3.15 3 38 126610.2900 1.90 5.7 3 38 126610.4600 2.75 8.25 3 38
126610.1300 1.10 3.3 3 38 126610.3000 1.95 5.85 3 38 126610.4700 2.80 8.4 3 38
126610.1400 1.15 3.45 3 38 126610.3100 2.00 6 3 38 126610.4800 2.85 8.55 3 38
126610.1500 1.20 3.6 3 38 126610.3200 2.05 6.15 3 38 126610.4900 2.90 8.7 3 38
126610.1600 1.25 3.75 3 38 126610.3300 2.10 6.3 3 38 126610.5000 2.95 8.85 3 38
126610.1700 1.30 3.9 3 38 126610.3400 2.15 6.45 3 38 126610.5100 3.00 9 6 51
