072570 Compression load cells
Ring version. The centre drilling in the pressure plate allows it to be used with push rods and pull
rods. Model with trailing pointer, applying the hydraulics principle. Suitable for measuring axial
forces on shafts, spindles, clamp screws and tension screws, and traction forces.
Features:
Acuracy is ±2% of maximum scale value
optimum accuracy is at the centre of the scale
Note:
Version with larger measuring ranges on request
Package contents:
Delivered in transport packaging.

Order ID Range Range Resolution Resolution Hole Cell Ø Cell height Pressure gauge Ø Weight
N daN daN N mm mm mm mm kg
072570.0100 1000 100 5 50 20 90 38 63 1.7
072570.0200 1600 160 5 50 20 90 38 63 1.7
072570.0300 2500 250 10 100 20 90 38 63 1.7
072570.0400 4000 400 20 200 20 90 38 63 1.7
072570.0500 6000 600 20 200 20 90 38 63 1.7
072570.0600 10000 1000 50 0,5 20 90 38 63 1.7
072580 Compression load cells
Version with stepped cell, suitable for measuring the clamping forces in vices etc. (installed verti-
cally). Note: the jaw height must go beyond the centre point of the pressure plate.
Features:
Piston stroke 0.5 mm max
Acuracy is ±2% of maximum scale value
Maximum piston cant of up to 13°
Pressure gauge with trailing pointer
Note:
Version with larger measuring ranges on request
Package contents:
Delivered in transport packaging.

Order ID Range Range Resolution Resolution Cell Ø Cell height Pressure Weight
gauge Ø
N daN daN N mm mm mm kg
072580.0100 250 25 1 10 90 37 63 1.7
072580.0200 400 40 2 20 90 37 63 1.7
072580.0300 600 60 2 20 90 37 63 1.7
072580.0400 1000 100 5 50 90 37 63 1.7
072580.0500 1600 160 5 50 90 37 63 1.7
072580.0600 2500 250 10 100 90 37 63 1.7
072580.0700 4000 400 20 200 90 37 63 1.7
072580.0800 6000 600 20 200 90 37 63 1.7
072580.0900 10000 1000 50 500 90 37 63 1.7
