072725 Tension meter Zivy TEN
stationary model
Swiss Made - Small, compact, mechanical tensile stress measurement instrument for low tensile
stresses of fibres and yarns.
Features:
Housing made of aluminium
2-roller system
Large fibre loop
V-grooved guide rollers made of aluminium, ball-bearing mounted, blackened
Guide roller throughput speed 900m/min (Vmax)
Accuracy ±1.5% of the entire measuring range (full scale) or ±1 digit
Note:
Thread the material to be measured in such a way that it is positioned between the two guide rol-
072725.0070 lers. Push and hold the button on the instrument. The outer roll is pivoted to the top and the device
is ready to measure. The tensile stress measured is displayed on the precision gauge.
Package contents:
Delivered in transport packaging with roller wrench, operating manual in German, French, English
and Italian.
Order ID Type Range Bezel Ø Operating temperature Weight
mm °C g
072725.0010 1751 TEN 5 gr. Stat. 1…5 g 40 10...50 150
072725.0020 1751 TEN 12 gr. Stat. 2…12 g 40 10...50 150
072725.0030 1751 TEN 30 gr. Stat. 5...30 g 40 10...50 150
072725.0050 1751 TEN 50 gr. Stat. 10...50 g 40 10...50 150
072725.0060 1751 TEN 60 gr. Stat. 10...60 g 40 10...50 150
072725.0070 1751 TEN 70 gr. Stat. 10...70 g 40 10...50 150
072725.0100 1751 TEN 170 gr. Stat. 50…170 g 40 10...50 150
072878 Hanging scales digital KERN
Model with stainless steel hook and handle for versatile use.
Features:
LCD display
Simple operation
Tare function
Peak hold function
Selectable weighing unit
Auto-OFF function
Integrated tape measure 1 m
Package contents:
Delivered in transport packaging.
Appropriate batteries:
1 pieces 055050.0700 - 6LR61 / 9.0 V (included in scope of delivery).
Order ID Scales capacity Resolution Digit height Dimensions WxDxH Weight
kg g mm mm kg
072878.0020 15 20 11 90 x 30 x 176.5 0.25
072878.0040 50 50 11 90 x 30 x 176.5 0.25
072878.0060 50 100 11 90 x 30 x 176.5 0.25

072888 Hanging scales digital PESOLA
Compact hanging models for simple and versatile use.
Designs:
072888.0100: With swivelling handle and flexible hooks. Automatic HOLD function.
072888.0140...072888.0160: With solid galvanised steel carabiner and S-hook made of stainless
steel. Illuminated LCD display.
Features:
Automatic zero setting at startup
Large LCD display
Choice of weighing units kg, g, lb, oz
Tare/hold function
Display battery low voltage
Display overload [EEEE]
Calibration function
Appropriate batteries:
072888.0100: 2 pieces 055050.0400 - LR03 / 1.5 V (AAA) (included in scope of delivery).
072888.0140...072888.0160: 2 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of de-
livery).
Order ID Scales capacity Resolution
kg g
072888.0100 40 10
072888.0140 100 100
072888.0160 200 200
072888.0100
