072435 Test stand MECMESIN Helixa-xt
Controlled via console
Helixa-xt – Torque test stand, console-controlled for measuring low and medium torques with
convenient touchscreen. Especially developed for easy use in shops and for routine checks in quality
control labs where no external PC or laptop is to be used.
Features Software:
Test stand control via touchscreen console
Data capture rate max. 1000Hz
Password-protected login
Several languages available
Quick access to 5 Favorites programs
3 different program modes available
Test reports can be custom adapted
Easy programming and use
Features Test stand:
1-column style / sturdy construction
Precise directionality of the torque transmitter possible
Balanced cross arm (no vertical forces)
Easily adjustable cross arm height
Quick change of torque transmitter possible
Rotational direction control keys for clockwise and anticlockwise direction
Emergency switch on the front panel
Precision drive with real-time
Useful height 360 mm
Projection by means of bellows 112 mm
True running accuracy without accessories ±0.25 mm
Clamping fixture (optional)
Can be used with:
Torque transmitter HTC 072440
Suitable for product testing according to the following standards:
BS EN 1707 / ISO 594 (ISO 80369) - conical connectors for syringes, needles and medical equipment
ISO 11608 - needle-based injection systems for medical use
ASTM D3810 / ASTM D3968 - child-resistant safety locks
ASTM D3198 - threaded locks
ISO 6475 - metal bone screws for implants
User training is definitely required for this product
in order to operate the test stand safely and to be able to use the software optimally.
For further information, please ask for a special brochure or for advice.
Package contents:
Delivered in transport packaging including touchscreen console, cables including USB converter,
software and operating manual, without torque transmitter, without clamping fixture.
Appropriate accessories:
Torque transmitter HTC 072440
Accessories 072391
Note:
* Total height of the test stand
Order ID Range Maximum displacement Displacement resolution Speed range Height Weight
revs ° min -1 mm kg
072435.0100 0.1 / 0.3 / 1.5 / 3 / 6 Nm 2500 0.2 0.1...30 758* 32
