Load and pressure measuring instruments / Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
072410 Torque tester MECMESIN Tornado
Tornado - For measuring and checking the torque when screwing or unscrewing a test piece. Large
LCD display in stable light alloy housing for manual use. Measurement display mode can be set to
continuous display or peak value capture, when unscrewing or screwing.
Features:
Accuracy ±0.5% of the full measuring range
Selectable units of measurement
Data output RS-232, Digimatic
Direct connection for MITUTOYO miniprocessor 054060
500 measurements can be saved
Programmable alarm
Package contents:
Delivered in plastic case incl. batteries, plug-in mains adapter and factory certificate.
Appropriate batteries:
Application 5 pieces 055060.0120 - HR03 / 700 mAh / 4 x 1.2V (AAA) / B4 (included in scope of delivery).

Appropriate accessories:
Software 072352.0100
MITUTOYO miniprocessor 054060
Order ID Range Resolution Clamping Weight Protection
area Ø class
Nm Nm mm kg
072410.0100 0...1.5 0.0005 10...78 2.65 IP54
072410.0200 0...3 0.001 10...78 2.65 IP54
072410.0300 0...6 0.002 10...190 3 IP54
072410.0400 0...10 0.002 10...190 3 IP54
072420 Test stand MECMESIN Vortex-dV
Controlled via front panel
Vortex-dV - Motorised torque test stand controlled via front panel. For use with AFTI display unit
and torque transducer for measuring clockwise and anti-clockwise torques. Ideal for all areas of
quality control.
Features:
Control via front panel
Digital display - speed / angle
Selection of speed via potentiometer
Emergency stop button
Data output RS-232 for analysis using the software
Autom. stop of rotary movement (optional)
Clamping fixtures (optional)
For use with:
Display unit AFTI 072170.0100
Torque transducer 072430
Note:
* Total height of the test stand
We strongly recommend user training for this software, in order to be able to make the
most efficient use of its capabilities right from the start. For more technical information,
please request a special brochure or advice.
Package contents:
Delivered in transport packaging. Does not include AFTI display unit, torque transducer, or clam-
ping fixtures.
F072420.0200
Appropriate accessories:
Fixing plates 072391.2040 / 072391.2045
Accessories 072391
Software 072352.0100
Order ID Range Speed range Height Weight
Nm min -1 mm kg
072420.0100 1.5/3/6/10 0.1...20 1025* 20
072420.0200 1.5/3/6/10 0.1...20 1025* 20
