Load and pressure measuring instruments / Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
072334 Test stand MECMESIN MultiTest - i
Controlled via PC
MultiTest i - Test stand for measuring tension and pressure, which is controlled either via PC or
laptop. Designed for quality control in the measuring laboratory, in research and development. The
software offers versatile options for controlling motion sequences, and measuring and analysing
forces.
Software features:
Control of the test stand via PC or laptop
Data capture rate max. 1000Hz
Password protected login
Several languages available
Instant access to 5 favourite programs
2 different program modes to choose from
Versatile programming and evaluation options
Link for data exports to EXCEL
Customised test reports
For use with:
ILC Load cells MECMESIN 072335 (must be ordered separately)
Note:
* Total height of the test stand
** Without load cell or accessories
User training is necessary for this product in all cases,
in order to be able to operate the test stand safely and make optimum use of the soft-
ware.
For further technical information, please ask for a special brochure or for advice.
Package contents:
MultiTest 5-i application Test stand with software, cable with USB converter, operating instructions. Delivered in transport
packaging, load cell and PC not included.
Appropriate accessories:
ILC Load cells MECMESIN 072335
Accessories 072391
Order ID Type Measuring pressure max. Traverse path max. Traverse speed Height Weight
N mm mm/min mm kg
072334.0050 MultiTest 0.5-i 500 1200** 1...1000 1710* 38
072334.0100 MultiTest 1-i 1000 1000** 1...1000 1510* 36
072334.0200 MultiTest 2.5-i 2500 500** 1...1000 941* 22
072334.0300 MultiTest 5-i 5000 590** 1...500 1082* 38
072334.0400 MultiTest 10-i 10000 960** 1...1000 1500* 110
072334.0500 MultiTest 25-i 25000 950** 1...1000 1500* 140
072334.0600 MultiTest 50-i 50000 1100** 1...400 1931* 285
072335 Load cell MECMESIN ILC
ILC - Load cell for connecting to the motorised test stands. Suitable for compression and tension
measurements.
Features:
Accuracy ±0.1% of the full measurement range from 2N...2500N
Accuracy ±0.2% of the full measurement range from 5000N...50000N
Package contents:
Delivered incl. factory certificate.
Order ID Type Range Resolution Holder
N N
072335.0100 ILC 2 0.0003 10/ 32UNF
072335.0200 ILC 5 0.0008 10/ 32UNF
072335.0300 ILC 10 0.002 10/ 32UNF
072335.0400 ILC 25 0.004 10/ 32UNF
ILC 072335.0500 ILC 50 0.008 10/ 32UNF
072335.0600 ILC 100 0.02 10/ 32UNF
072335.0700 ILC 250 0.04 10/ 32UNF
072335.0800 ILC 500 0.08 10/ 32UNF
072335.1500 ILC-S 100 0.02 M6
072335.1600 ILC-S 200 0.03 M6
072335.1700 ILC-S 500 0.08 M6
072335.1800 ILC-S 1000 0.2 M10
072335.1900 ILC-S 2500 0.4 M12
072335.2000 ILC-S 5000 0.8 M12
072335.2500 ILC-T 10000 1.5 M12
072335.2600 ILC-T 25000 3.9 M16
ILC-S 072335.2700 ILC-P 50000 7.7 -
