      072235   Load cell MECMESIN

      LBC Mini Smart - Pressure- For use with the AFTI display unit or with the AFG force measuring
      device.
      Features:
      only for pressure
      Accuracy ±1% of the full measuring range
      Smart-connection/connection cable 1.5 m
      Note:
      Ideal for applications in cramped spaces.
      Package contents:
      Delivered in transport packaging incl. factory certificate.
      Appropriate accessories:
      Display unit AFTI  072170.0100
      Accessories 072391
      Order ID  Model  Range  Resolution  D1  D2  D3  H1  H2  T
                        N      N    mm  mm   mm  mm  mm
      072235.0040 L16010  100  0.02  25  5   19   8   1  4/40 UNC
      072235.0050 L16010  250  0.05  25  5   19   8   1  4/40 UNC
      072235.0060 L16010  500  0.1   25  5   19   8   1  4/40 UNC
      072235.0070 L16020  1000  0.2  31  8   25  10   1  6/32 UNC
      072235.0080 L16020  2500  0.5  31  8   25  10   1  6/32 UNC
      072235.0090 L16020  5000  1    31  8   25  10   1  6/32 UNC
      072235.0100 L16020  10000  2   31  8   25  10   1  6/32 UNC
      072235.0200 L16030  20000  4   38  11  32  16   2  6/32 UNC
      072235.0300 L16030  50000  10  38  11  32  16   2  6/32 UNC
      072240   Load cell MECMESIN
      LBC Sub-Mini Smart - pressure - For use with the display unit AFTI or with the force gauge AFG.
      Features:
      Accuracy ±1% of the full measuring range
      only resilient to pressure
      Smart connector / connecting cable 1.5 m
      Note:
      Ideal for applications in cramped spaces.
      Package contents:
      Delivered in transport packaging incl. factory certificate.
      Appropriate accessories:
      Display unit AFTI  072170.0100
      Accessories 072391
      Order ID   Range    Resolution  D1     D2     H1      H2
                   N         N       mm      mm     mm     mm
      072240.0200  100      0.02      19     4.5     7      0.5
      072240.0300  250      0.05      19     4.5     7      0.5
      072240.0400  500      0.1       19     4.5     7      0.5
      072240.0500  1000     0.2       19     4.5     7      0.5
      072240.0600  5000      1        19     4.5     7      0.5



      072250   Torque transducer MECMESIN TS
      TS Smart - Torque - For use with the display unit AFTI or with the force gauge AFG. Rugged metal
      housing with three-jaw chuck; for clockwise and anticlockwise measurements.
      Features:
      Accuracy ±0.5% of the full measuring range
      Smart connector / connecting cable 0.5 m (extensile)
      Package contents:
      Delivered in transport packaging incl. factory certificate.
      Appropriate accessories:
      Display unit AFTI  072170.0100
      Order ID    Type   Range   Resolution  Clamping width  Weight
                          Nm       mNm         mm           g
      072250.0050  TS 0.3  0...0.3  0.1        1...10      660
      072250.0100  TS 1.5  0...1.5  0.3        1...10      660
      072250.0150  TS 3   0...3    0.6         1...10      660
      072250.0200  TS 6   0...6     2          1...10      660
      072250.0300  TS 10  0...10    2          1...10      660
