Load and pressure measuring instruments / Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
072312 Test stand MECMESIN MultiTest-dV
Motorised
MultiTest-dV - Motorised test stand for use with MECMESIN AFG force gauges for measurement
of compression and tension. Ideal for all areas of quality control.
Features:
Control via front panel at the base of the stand
Multifunctional wheel for precise setting of speed and position
Single and multiple cycles possible
Control panel indicates speed, displacement and load (when AFG connected)
Emergency stop button
Mechanical safety stops
Usable with:
Force gauge MECMESIN AFG 072120
Note:
We recommend training for first-time users! For further information, please ask for a
special brochure or for
advice.
Package contents: Delivered in transport packaging
Appropriate accessories:
Force gauge MECMESIN AFG 072120
Accessories 072391
Software 072352.0100 (MultiTest-dV)
Order ID 072312.1110 072312.1210 072312.1310
Type 0.5-dV 1-dV 2.5-dV MultiTest 2.5-dV
Measuring pressure max. N 500 1000 2500
Traverse path max. mm 1200 1000 500
Traverse speed mm/min 1...1000 1...1000 1...1000
Height mm 1710 1510 941
Weight kg 45 43 29
072322 Test stand MECMESIN MultiTest - xt
Controlled via touchscreen console
MultiTest xt - Console-controlled, rugged test stand with convenient touchscreen for measuring
tension and pressure. Specially developed for simple use in workshops and for routine checks in
quality laboratories where external PCs or laptops should not be used.
Features Software:
Test stand via touchscreen console
Data capture rate max. 1000Hz
Password-protected login
Several languages available
Rapid acces to 5 Favorites programs
3 different program modes available
Test reports can be custom adapted
Easy programming and use
Features Test stand:
Sturdy 1- or 2-column style
Direction control keys on the front panel
Emergency switch on the front panel
Precision drive with real-time controller
Can be used with:
ILC load cell MECMESIN 072335 (must be ordered separately)
Note:
* Overall height of the test stand
** Movement range without load cell or accessories
User training is necessary for this product in all cases,
in order to be able to operate the test stand safely and make optimum use of the soft-
ware.
For further information, please ask for a special brochure or for advice.
MultiTest 2.5-xt
Package contents:
Delivered in transport packaging without load cell.
Appropriate accessories:
ILC load cell MECMESIN 072335
Accessories 072391
Order ID Type Measuring Traverse path Resolution Height Traverse speed Weight
pressure max. max. traverse path
N mm mm mm mm/min kg
072322.1005 MultiTest 0.5-xt 500 1200** 0.01 1710* 1...1000 43
072322.1105 MultiTest 1-xt 1000 1000** 0.01 1510* 1...1000 41
072322.1205 MultiTest 2.5-xt 2500 500** 0.01 941* 1...1000 27
072322.1305 MultiTest 5-xt 5000 590** 0.01 1082* 1...500 43
072322.1405 MultiTest 10-xt 10000 960** 0.01 1500* 1...1000 115
072322.1505 MultiTest 25-xt 25000 950** 0.01 1500* 1...1000 145
072322.1605 MultiTest 50-xt 50000 1100** 0.01 1931* 1...400 290
