072280 Universal test stand MECMESIN LCP/S
Manual
LCP/S - Manual test stand with manual lever for use with MECMESIN force measuring devices.
Suitable for measuring tensile and compressive forces. The lever permits fast manual vertical ad-
justment.
Designs:
072280.0100: Test stand without calliper gauge
072280.0200: Test stand including installed calliper gauge
Usable with:
Digital force measuring device MECMESIN AFG 072120
Standard accessories:
Mounting plate for force measuring device AFG, stand baseplate with 2 holes: M6 and 10-32 UNF.
Package contents: Delivered in transport packaging .
Order ID Measuring Traverse path Height Weight Version
pressure max. max.
N mm mm kg
072280.0100 500 170 360 4.5 Test stand wi-
thout calliper
gauge
072280.0200 500 170 360 4.5 Test stand
including ins-
talled calliper
gauge
072290 Universal test stand MECMESIN MDD
Manual
MDD - Manual test stand with hand lever for use with load gauges MECMESIN. Suitable for
measuring tension and pressure. Per crank rotation 2 mm height adjustable. The universal test
stand can also be used horizontally with optional accessories.
Designs:
072290.0100: Test stand without calliper gauge
072290.0200: Test stand including installed calliper gauge
Can be used with:
Force gauge digital MECMESIN AFG 072120
Standard accessories:
Mounting bracket for AFG load gauges, anvil base plate with 2 mounting holes: M6 and 10-32
UNF.
Package contents: Delivered in transport packaging.
Order ID Measuring pressure max. Traverse path max. Height Weight Version
N mm mm kg
072290.0100 1000 360 635 6 Test stand without
calliper gauge
072290.0200 1000 360 635 6 Test stand
including installed
calliper gauge
072291 Test stand MECMESIN ValuTest-D
Manual
ValuTest-D - Simple manual test stand with hand crank for use with load gauges MECMESIN.
Suitable for measuring tension and pressure. Per crank rotation 3 mm height adjustable.
Can be used with:
Force gauge MECMESIN CFG+ 072110
Package contents:
Delivered in transport packaging.
Order ID Measuring pressure max. Traverse path max. Height Weight
N mm mm kg
072291.0100 1000 258 406 6
application
