Load and pressure measuring instruments / Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
072130 Force gauge MECMESIN MYOMETER
MYOMETER - Tension + compression - instrument for evaluating shoulder function and monito-
ring muscle strength. For physicians, surgeons and medical care and technical staff for evaluating
post-operation muscle strength, comparisons before and after a procedure, information about the
progress of a medical condition, results of a treatment or a training effect.
With large LCD display in sturdy light alloy casing.
Designs:
072130.0100: incl. software
072130.0200: without software
Features:
Accuracy ±0.1% of full range
Data sampling rate 5000 Hz
Units of measurement can be converted - N, kN, kgf, ozf, lbf
Mode CONSTANT SCORE - load after 2 and 3 seconds
Mode MAX - MaxC; MaxT; MaxDual
Alarm function - acoustic and visual
Display can be turned 180°, background lighting
Data output RS232
Package contents:
Delivered in plastic case with charger, adapter, shackle, pull cable, universal retaining clip and
factory certificate.
Appropriate batteries:
5 pieces 055060.0120 - HR03 / 700 mAh / 4 x 1.2V (AAA) / B4 (included in scope of delivery).
Appropriate accessories:
Accessories 072391
Calibration weights 073455...173500
Software 072352.0100
Order ID Type Range Resolution Weight Version
N N g
072130.0100 MYOMETER 1000 0.2 560 incl. software
072130.0200 MYOMETER 1000 0.2 560 without software
072135 Force gauge MECMESIN PENETROMETER
Shotcrete PENETROMETER - compression - force gauge for testing the strength of sprayed con-
crete to BS EN 14488-2 (Method A). With large LCD display in sturdy light alloy casing.
Features:
Accuracy ±0.1% of full-scale
Data sampling rate 2000Hz (5000Hz)
Recording of the maximum value
Measurement units can be converted, N, kN...
Limit value setting - acoustic and visual
Stores up to 100 measurements
Data output RS-232, digimatic and analog
Package content:
Delivered in plastic case incl. needle adapter + 15 needles, charger and factory certificate.
Appropriate batteries:
5 pieces 055060.0120 - HR03 / 700 mAh / 4 x 1.2V (AAA) / B4 (included in scope of delivery).
Appropriate accessories:
Accessories 072391
Calibration weights 073455...173500
Software 072352.0100
Order ID Type Range Resolution Weight
N N g
072135.0100 PENETROMETER 1000 0.2 560
072170 Display unit digital MECMESIN AFTI
AFTI - tension + pressure & torque - With large LCD display in sturdy light alloy casing. Exclusi-
vely for use with load cells MECMESIN. For various manual tasks, integrated in process devices
or on test stands. Measurement display mode for continuous display or peak value memory. This
instrument is a indicating device and has no intern load cell.
Features:
Automatic identification of the load cell
Data scan rate 2000Hz (5000Hz)
Selectable measurement units: N, kN, lbf, kgf, Nm, kgfcm, lbfin, gfcm
Maximum value memory / limit value setting - acoustic and visual
Memory stores up to 100 measurements
Data output RS-232, Digimatic and analogue
Package contents: Application with transducers
Supplied in plastic case with charger.
Appropriate batteries:
5 pieces 055060.0120 - HR03 / 700 mAh / 4 x 1.2V (AAA) / B4 (included in scope of delivery).
Appropriate accessories:
Capteur de force 072190...172240
Accessories 072391
Calibration weights 073455...173500
Software 072352.0100
Order ID Designation Weight
g
072170.0100 Display unit MECMESIN AFTI 500

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 367
