Load and pressure measuring instruments / Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
072120 Force gauge MECMESIN AFG
AFG - tension + compression - With large LCD display in stable light alloy casing, for a wide
range of manual applications or on test stands for either tension or compression. Measurement
display can be set to continuous display or peak value capture.
Features:
Accuracy ±0.1% of the full measuring range
Data scan rate 2000Hz (5000Hz)
Selectable measurement units depending on model: mN, kN, gf, kfg ozf, lbf
Limit value setting - acoustic and visual
Memory stores up to 100 measurements
Connection for external MECMESIN load cell
Data output RS-232, Digimatic and analogue
Package contents:
Delivered in plastic case with charger, load hook, pressure plate, extension and factory certificate.
Appropriate batteries:
5 pieces 055060.0120 - HR03 / 700 mAh / 4 x 1.2V (AAA) / B4 (included in scope of delivery).
Appropriate accessories:
Accessories 072391
Calibration weights 073455...173500
Software 072352.0100
Order ID Type Range Resolution Threaded con- Weight
nection (bolt)
N N g
072120.0100 AFG 2.5N 2.5 0.0005 10-32 UNF 560
072120.0200 AFG 5N 5 0.001 10-32 UNF 560
072120.0300 AFG 10N 10 0.002 10-32 UNF 560
072120.0400 AFG 25N 25 0.005 10-32 UNF 560
072120.0500 AFG 50N 50 0.01 10-32 UNF 560
072120.0600 AFG 100N 100 0.02 10-32 UNF 560
072120.0700 AFG 250N 250 0.05 10-32 UNF 560
072120.0800 AFG 500N 500 0.1 10-32 UNF 560
072120.0900 AFG 1000N 1000 0.2 5/16 UNC 560
072120.1000 AFG 2500N 2500 0.5 5/16 UNC 560
072125 Manual operation kit MECMESIN AFG
This practical operation kit including force gauge 2500N and various accessories offers optimum
possibilities for manual operation in a wide range of applications. In addition, the case offers opti-
mum protection for the force gauge and room for accessories.
Note:
Details for load gauge - see for AFG 072120
Package contents:
Case
Force gauge 2500N (072120.1000)
Holder for 2-hand operation (072391.1440)
072125.0100 Chain link and hook set (072391.1465)
Pressure plate nickel-plated, rubber-coated 50 mm (072391.1180)
Appropriate batteries:
5 pieces 055060.0120 - HR03 / 700 mAh / 4 x 1.2V (AAA) / B4 (included in scope of delivery).
Appropriate accessories:
Accessories 072391
Calibration weights 073455...173500
Software 072352.0100
Order ID Type Range Resolution
N N
072125.0100 AFG 2500N 2500 0.5

366 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
