Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
063426 Parallel gauge block FUTURO, steel
Tolerance class 1 - DIN EN ISO 3650 - The gauge blocks most often used as working standards
for setting and calibrating gauges and measuring devices, and in testing rooms and production
inspection areas.
Package contents:
Delivered incl. calibration certificate.
Order ID Length Order ID Length Order ID Length
mm mm mm
063426.0410 0.50 063426.1690 4.00 063426.2040 19.00
063426.1000 1.00 063426.1710 5.00 063426.2060 20.00
063426.1010 1.0005 063426.1740 6.00 063426.2090 21.00
063426.1060 1.005 063426.1760 7.00 063426.2110 22.00
063426.1200 1.10 063426.1790 8.00 063426.2140 23.00
063426.1300 1.20 063426.1810 9.00 063426.2160 24.00
063426.1400 1.30 063426.1830 10.00 063426.2180 25.00
063426.1500 1.40 063426.1860 11.00 063426.2190 30.00
063426.1600 1.50 063426.1880 12.00 063426.2200 40.00
063426.1610 1.60 063426.1910 13.00 063426.2210 50.00
063426.1620 1.70 063426.1930 14.00 063426.2220 60.00
063426.1630 1.80 063426.1950 15.00 063426.2230 70.00
063426.1640 1.90 063426.1970 16.00 063426.2250 80.00
063426.1650 2.00 063426.1990 17.00 063426.2260 90.00
063426.1670 3.00 063426.2020 18.00 063426.2270 100.00 With calibration certificate
079830 Fit selector
German - French - Made of plastic, 110 x 280 mm, with all essential data regarding fits.
Front side: 34 tolerance fields
DIN 7157 nominal size range 1...500 mm.
Back side: 35 fits
DIN 7157 nominal size range 1...500 mm.
Order ID Size
mm
079830.0100 Ø 1...500
