048475 Roughness tester MITUTOYO SURFTEST
SURFTEST SJ 411 / SJ412 - Multifunctional mobile roughness tester for reference level measure-
ment of primary profile, roughness, waviness and more. Suitable for use with skidded probes
or skidless probes. The device can be conveniently configured via the colour LCD touch panel and
measurement values can be displayed. Printout via integrated thermal printer.
Designs:
048475.0100: Measurement range X-axis = 25 mm
048475.0200: Measurement range X-axis = 50 mm
Features:
Easy-to-use LCD touch panel (colour)
Graphical representation of the profiles
Inclination compensation
Memory for 10 measurement parameters
Evaluation of steps and straightness
Automatic radius/inclination compensation
Evaluation of tolerances (colour)
Statistics function (max./min./standard deviation...)
Arbitrary measurement lengths adjustable
Auto-calibration function
Complies with DIN EN ISO, VDA, ANSI, JIS
16 languages, password protection
Parameters include:
Ra, Rq, Ry, Rz, Rp, Rt, R3z, Wt, Pt (45 in total)
Filter: 2CR, PC75, Gaussian
Data output:
RS-232C, Digimatic, USB
Note:
We recommend training for first-time users! For further technical information, please ask
for a special brochure or for advice.
Package contents:
Basic unit with integrated thermal printer, feeder device SJ-410 with standard probe,pPower sup-
ply/batteries, carry-case
Appropriate accessories:
048480 Accessories
048120 Roughness standard
Order ID 048475.0100 048475.0200
Type SJ 411 SJ 412
Range µm 800/80/8 800/80/8
Resolution µm 0.0001 0.0001
Feeder length mm 25 50
Probe sections mm 0...25 0...50
Weight kg 2.1 2.1
