3D Probe elements Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
047000 M5 Sensor joints NÜSSLER
Aluminium 7075 / type NGA
Order ID L d1 D Weight
mm mm mm g
047000.0010 30.0 M5 11.0 7

047110 M6 NÜSSLER adapter for FARO 3-D measuring arms
Order ID Type L G
mm
047110.0010 M6 / M2 (FARO) 38 M2
047110.0020 M6 / M3 (FARO) 38 M3
047110.0030 M6 / M4 (FARO) 38 M4 047110.0010...0040
047110.0040 M6 / M5 (FARO) 38 M5
047110.0100 1 1/4-20 UNF/M2 (FARO) 41 M2
047110.0110 1 1/4-20 UNF/M3 (FARO) 41 M3
047110.0120 1 1/4-20 UNF/M4 (FARO) 41 M4
047110.0130 1 1/4-20 UNF/M5 (FARO) 41 M5
047110.0140 1 1/4-20 UNF/M6 (FARO) 41 M6
047110.0100...0140
047120 M6 Sensor insert NÜSSLER
Carbide shank, ruby / ceramic / carbide ball / type B
For applications on FARO 3D measuring arms.
Order ID Type dk d1 L ML
mm mm mm mm
047120.0010 BR 3 2 48 10
047120.0020 BZ 3 2 48 10
047120.0030 BH 3 2 48 10
047120.0040 BR 6 3 48 10
047120.0050 BZ 6 3 48 10
047120.0060 BH 6 3 48 10

047130 11/4-20 UNF Sensor insert NÜSSLER
Carbide shank, ruby / ceramic / carbide ball / type B
For applications on FARO 3D measuring arms.
Order ID Type dk d1 L ML
mm mm mm mm
047130.0010 BR 3 2 60 10
047130.0020 BZ 3 2 60 10
047130.0030 BH 3 2 60 10
047130.0040 BR 6 3 60 10
047130.0050 BZ 6 3 60 10
047130.0060 BH 6 3 60 10

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 227
