Surfaces, form, contours measuring techn. Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
048461 Roughness tester MITUTOYO SURFTEST
SURFTEST SJ 210 - The portable tester with flexible on-site application. This compact surface tester
excels due to its outstanding user comfort during daily routine work.
Designs:
048461.0100: Standard drive unit
048461.0200: R-drive unit (retractable)
048461.0300: S-drive unit (transverse tracing)
Features:
LCD colour display screen
Calibration function
Memory for measurement parameters
Multilingual
Data output USB, MicroSC card
Parameters include:
Ra, Rq, Ry, Rz, Rp, Rt, R3z (39 in total)
Note:
For this product we recommend a training!
For further technical information, please ask for our special brochure or for advice.
Package contents:
Basic device with drive unit and standard detector
Roughness comparator, Ni-Cd battery, power supply unit and case
Appropriate accessories: Application with cable
048480 Accessories
048120 Roughness standard
Order ID 048461.0100 048461.0200 048461.0300
Type SJ-210 SJ-210 R SJ-210 S
Range µm 360 360 360
Resolution µm 0.002...0.025 0.002...0.025 0.002...0.025
Feeder length mm 17.5 17.5 5.6
Probe sections mm 0...16 0...16 0...16
Measuring force mN 0.75 0.75 0.75
Weight kg 0.5 0.5 0.5
048470 Roughness tester MITUTOYO SURFTEST
SURFTEST SJ 310 - Mobile roughness tester with built-in thermal printer. With the LCD touch
panel, configuring the device and displaying measured profiles is easy.
Designs:
048470.0200: Standard drive unit
048470.0210: R-drive unit (retractable)
048470.0220: S-drive unit (transverse tracing)
Features:
Easy-to-use LCD touch panel (colored)
Graphical display of profiles
Overhead measurement is possible
Memory for 10 measurement parameters
Statistic fonction (max/min/average...)
Evaluation of tolerance (colored)
Automatic calibration function
In accordance with DIN EN ISO, VDA, ANSI, JIS
16 languages
Parameters include:
Ra, Rq, Ry, Rz, Rp, Rt, R3z (45 in total)
Filter: 2CR75, PC75, Gauss
Data output:
RS-232C, Digimatic, USB
Note:
For this product we recommend a training!
For further technical information, please ask for our special brochure or for advice.
Package contents:
Basic device with case, drive unit with standard detector, roughness comparator and battery
Appropriate accessories:
048480 Accessories
048120 Roughness standard
Order ID 048470.0200 048470.0210 048470.0220
Type SJ-310 SJ-310 R SJ-310 S
Range µm 350 350 350
Resolution µm 0.002...0.025 0.002...0.025 0.002...0.025
Feeder length mm 17.5 17.5 5.6
Probe sections mm 0...16 0...16 0...16
Weight kg 1.7 1.7 1.7

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 231
