049170 Accessories ConturoMatic
Order ID Designation Sensor point Length
mm mm
049170.0050 Standard contour-roughness KRN60 - -
049170.0055 Calibration standard contour CV120 - -
Mini
049170.0100 Sensor arm contour for T1/T2/T3/TS/ 20.5 150
TS-R/TS-UD/TS-UDR/TS-X, 150 / 20.5
049170.0110 Sensor arm contour for T1/T2/T3/TS/ 6 150
TS-R/TS-UD/TS-UDR/TS-X, 150 / 6
049170.0500 Sensor arm contour for T1/T2/T3/TS/ 6 260
TS-R/TS-UD/TS-UDR/TS-X/CV250, 260 / 6
049170.0510 Sensor arm contour for T1/T2/T3/TS/ 33 260
TS-R/TS-UD/TS-UDR/TS-X/CV250, 260
/ 33
049170.0520 Sensor arm contour for T1/T2/T3/TS/TS- 59.5 260
UD/TS-X/CV250, 260 / 59.5
049170.1100 Sensor arm contour for T1/T3/TS-UD/TS- 2x 5 150
X, 150 / 2x 5
049170.1110 Sensor arm contour for T1/T3/TS-UD/TS- 2x 9 150
X, 150 / 2x 9
049170.1120 Sensor arm contour for T1/T3/TS-UD/TS- 2x 16.5 150
X, 150 / 2x 16.5
049170.1130 Sensor arm contour carbide - disc for T1/ 2x 1.25 190
T3/TS-UD/TS-X, 190 / 2x 1.25
049170.1140 Sensor arm contour ruby for T3/TS-X, 2x 9 150
150 / 2x 9 / Ø 1.5
049170.1510 Sensor arm contour ruby for T1/T3/TS- 2x 10 260
UD/TS-X, 260 / 2x 10 / Ø 1.0
049170.1520 Sensor arm contour carbide for T1/T3/ 2x 16.5 260
TS-UD/TS-X, 260 / 2x 16.5
049170.2100 Sensor arm roughness diamond for T1/ 6 190
T3/TS-UDR/TS-X, 190 / 6 / 60° / 2 µm
049170.2510 Sensor arm roughness diamond for T1/ 2x 5 190
T3/TS-UDR/TS-X, 190 / 2x 5 / 60° / 2 µm
049170.3010 Sensor arm contour ceramic for CV120, 4.5 120
120 / 4.5
049170.3020 Sensor arm contour ceramic for CV120, 6 120
120 / 6
049170.3040 Sensor arm contour ceramic for CV120, 20.5 120
120 / 20.5
049170.3050 Sensor arm contour ceramic for CV120, 33 120
120 / 33
049170.3210 Sensor arm contour carbide for CV120, 2.5 120
120 / 2.5
049170.3220 Sensor arm contour carbide for CV120, 6 120
120 / 6
049170.3230 Sensor arm contour carbide for CV120, 20.5 120
120 / 20.5
049170.3240 Sensor arm contour carbide for CV120, 33 120
120 / 33
049170.3245 Sensor arm contour carbide - cone for 33 120
CV120, 120 / 33
049170.3250 Sensor arm contour carbide for CV120, 59.5 120
120 / 59.5
049170.3255 Sensor arm contour carbide - cone for 59.5 120
CV120, 120 / 59.5
049170.4010 Sensor arm contour carbide - offset for 20.5 200
T1/T2/T3/TS/TS-UD/TS-X, 200 / 20.5 / 90°
049170.6000 Sensor tip contour ceramic, 20.5 / Ø 3.5 20.5 -
/ 12° / 25 µm
049170.6010 Sensor tip contour ceramic, 33.0 / Ø 3.5 33 -
/ 12° / 25 µm
049170.6020 Sensor tip contour ceramic, 59.5 / Ø 3.5 59.5 -
/ 12° / 25 µm
049170.6100 Sensor tip contour ceramic, 2x 5 / Ø 1.0 2x 5 -
/ 19° / 25 µm
049170.6110 Sensor tip contour ceramic, 2x 9 / Ø 1.5 2x 9 -
/ 14° / 25 µm
049170.6120 Sensor tip contour ceramic, 2x 16.5 / Ø 2x 16.5 -
2.5 / 12° / 25 µm
049170.6600 Sensor tip contour carbide, 20.5 / Ø 3.5 20.5 -
/ 12° / 25 µm
049170.6605 Sensor tip contour carbide - cone, 20.5 / 20.5 -
Ø 3.5 / 24° / 25 µm
049170.6610 Sensor tip contour carbide, 33.0 / Ø 3.5 33 -
/ 12° / 25 µm
049170.6615 Sensor tip contour carbide - cone, 33.0 / 33 -
Ø 3.5 / 24° / 25 µm
049170.6620 Sensor tip contour carbide, 59.5 / Ø 3.5 59.5 -
/ 12° / 25 µm
049170.6700 Sensor tip contour carbide, 2x 5 / Ø 1.0 2x 5 -
/ 19° / 25 µm
049170.6710 Sensor tip contour carbide, 2x 9 / Ø 1.5 2x 9 -
/ 14° / 25 µm
049170.6720 Sensor tip contour carbide, 2x 16.5 / Ø 2x 16.5 -
2.5 / 12° / 25 µm
