Surfaces, form, contours measuring techn. Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
048661 Roughness tester MAHR
MARSURF M300 Set
The perfect roughness tester for mobile use in workshop conditions. The Bluetooth interface bet-
ween the evaluation unit and drive unit means you can work more flexibly. An illuminated colour
display allows all important information about the measurement to be read easily at a glance. In
addition, most parameters and characteristics used by DIN/ISO/JIS/ASME/MOTIF can be applied for
evaluation of a measured profile.
Features:
Selectable measurement units µm/inch
Standards: switchable between ISO/ASME/JIS and MOTIF
Automatic standards/compliant selection of filter and traversing length
Tolerance monitoring in display and log
Automatic or adjustable scaling
Parameters:
DIN/ISO: Ra, Rq, Rz, Rmax, Rp, Rpk, Rk, Rvk, Rv, Mr1, Mr2, A1, A2, Vo, Rt, R3z, RPc, Rmr, RSm, Rsk
JIS: Ra, Rz, RzJIS, Sm, S, tp
ASME: Rp, Rpm
MOTIF: R, Ar, Rx, W, CR, CL, CF
Note:
For this product we recommend a training!
For further technical information, please ask for our special brochure or for advice.
Package contents:
Evaluation unit M 300
Feeder device RD 18 / Probe PHT 6-350
Roughness standard (integrated into feeder device)
2 x USB cable
Universal power supply unit 90 - 264 volts (with 3 adapters)
Operating manual
Probe protection
Factory protocol
Appropiates accessories:
048670 Accessories
048120 Roughness standard
Order ID Range Resolution Feeder length Probe sections Weight
µm µm mm mm kg
048661.0100 0...350 0.008 17.5 1.75 / 5.6 / 17.5 1.3
048662 Roughness tester MAHR
MARSURF M300C Set
The perfect roughness tester for mobile use in workshop conditions. Due to the slim dimensions
of the MarSurf RD 18 C cylindrical feeder unit, measurements can be taken even under
the most cramped conditions. The drive unit is connected to the evaluation unit by a cable. The
evaluation unit has an illuminated colour display. All important information on the measurement
can be read there at one glance. In addition, most parameters and characteristics used by DIN/ISO/
JIS/ASME/MOTIF can be applied for evaluation of a measured profile.
Features:
Selectable measurement units µm/µinch
Standards: switchable between ISO/ASME/JIS and MOTIF
Automatic standards/compliant selection of filter and traversing length
Tolerance monitoring in display and log
Automatic or adjustable scaling
Parameters:
DIN/ISO: Ra, Rq, Rz, Rmax, Rp, Rpk, Rk, Rvk, Rv, Mr1, Mr2, A1, A2, Vo, Rt, R3z, RPc, Rmr, RSm, Rsk
JIS: Ra, Rz, RzJIS, Sm, S, tp
ASME: Rp, Rpm
MOTIF: R, Ar, Rx, W, CR, CL, CF
Note:
For this product we recommend a training!
For further technical information, please ask for our special brochure or for advice.
Package contents:
Evaluation unit M 300 C
Feeder device RD 18 C
Probe PHT 6-350
Surface test standard PRN 10 with calibration certificate
2 x USB cable
Universal power supply unit 90 - 264 volts (with 3 adapters)
Operating manual
Appropiates accessories:
048670 Accessories
048120 Roughness standard
Order ID Range Resolution Feeder length Probe sections Weight
µm µm mm mm kg
048662.0100 0...350 0.01 17.5 1.75 / 5.6 / 17.5 1.1
