048060 Surface specimen RUGOTEST
For visual and tactile comparison of the surfaces of workpieces (for example, with the finger nail).
Nota:
Not for calibration for surface roughness measuring equipment.
Order ID Designation
048060.0100 048060.0100 Metalworking set 1
048060.0200 Handgrinding 2
048060.0300 Sand blasting 3
048060.0400 Manual filing 4
048060.0500 Manual polishing 5
048060.0600 Planing 101
048060.0700 Turning 102
048060.0800 Front milling 103
048060.0900 Surface grinding 104
048060.0800 048060.1000 Cylindrical grinding 105
048060.1100 Electrical discharge machining 107
048080 Surface inspection measurement standard MICROSURF
For visual and tactile comparison of the surfaces of workpieces (for example, with the finger nail).
Note:
Not for calibration for surface roughness measuring equipment.
Order ID Designation
048080.0100 Metal machining set 130
048080.0200 Face grinding 315
048080.0300 Cylindrical grinding 316
048080.0400 Facing 319
048080.0500 Lengthwise turning 320
048080.0600 Face milling 321
048080.0700 Electrical discharge machining 331

048080.0500
048090 Electrical discharge machining standard test surface
MICROSURF
Standard test surface MICROSURF 13 - table with 12 specimens according to the Charmilles rough-
ness parameters (VDI 3400).
Note:
Cannot be used for calibrating surface roughness testers.
Order ID 048090.0100
Code VDI 12 15 18 21 24 27 30 33 36 39 42 45
Value Ra [µm] 0.4 0.56 0.8 1.12 1.16 2.2 3.2 4.5 6.3 9.0 12.6 18.0
Value Rz [µm] 1.5 2.4 - 4.7 6.5 10.5 12.5 17.5 24.0 34.0 48.0 69.0
048120 Roughness standard FUTURO
Suitable for calibration of roughness testers.
Features:
Roughness measurement values
R : Mathematical mean surface roughness
a
R : Average peak-to-valley
z
R : Maximum peak-to-valley
max
Scope of delivery:
Delivered included ISO certificate.
Order ID Designation
048120.0100 Roughness standard for fonction test, Ra 3µm
