3D Probe elements Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
046920 M5 Cylinder sensor insert NÜSSLER
Steel shank, ruby cylinder / type ZRA
Order ID dz L1 L ML Weight D
mm mm mm mm g mm
046920.0010 2.0 5.0 25.0 14.0 6 11.0
046920.0020 3.0 10.0 25.0 14.0 6 11.0
046920.0030 4.0 10.0 30.0 21.0 7 11.0

046930 M5 Cylinder sensor tip NÜSSLER
HM / type S
Order ID d1 Beta L ML Weight D
mm mm mm g mm
046930.0010 3.5 30° 61.0 39.0 12 11.0

046940 M5 Spherical washer sensor insert NÜSSLER
Shank aluminium 7075, ceramic disc
Order ID dk L H Weight D
mm mm mm g mm
046940.0010 15.0 40.0 1.0 5 7.0
046940.0020 20.0 60.0 1.0 8 7.0

046950 M5 Sensor pin holder NÜSSLER
Steel / type HT
Order ID d1 L L1 Weight ds D
mm mm mm g mm mm
046950.0010 8.0 20 11 16 3.0 11

046970 M5 Probe extension NÜSSLER
Steel
Order ID D L Weight Order ID D L Weight
mm mm g mm mm g
046970.0010 11.0 10.0 6 046970.0050 11.0 40.0 28
046970.0020 11.0 15.0 10 046970.0060 11.0 60.0 42
046970.0030 11.0 20.0 13 046970.0070 11.0 80.0 56
046970.0040 11.0 25.0 17 046970.0080 11.0 100.0 70
046990 M5 Cube NÜSSLER
Aluminium 7075 / type NWA
Version for M5 sensor inserts.
Order ID D Weight
mm g
046990.0010 15 8
