Page 392 - Benma | Blue book 5.0

Load and pressure measuring instruments / Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
073200 Pocket spring balance
Housing and needle painted black, clasp and ring bright galvanised, dial plate brassed, not calib-
rated.
Order ID Scales capacity Resolution
kg kg
073200.0100 25 0.5
073200.0200 50 0.5
073200.0300 100 0.5

073220 Tension gauges CORREX
rounded feeler tip
The Correx tension gauge gives good results wherever small mechanical forces are to be measured.
Features:
Clockwise and anti-clockwise measurements
Double scale (g, cN, Pond)
Accuracy ±0.01 x (range + measuring value)
Trailing pointer to indicate maximum values, and ball probe
Appropriate accessories:
Calibration weights 073455
Package contents:
Delivered in own case.
Note:
*Without trailing pointer
Order ID Range Probe length
g/cN/Pond mm
073220.0100 0.3...3* 32
073220.0200 0.6...6* 32
073220.0300 2...15 32
073220.0400 3...30 32
073220.0500 5...50 32
073220.0600 10...100 32
073220.0700 15...150 32
073220.0800 25...250 32
073220.0900 50...500 47
073220.1000 100...1000 47
073220.1100 200...2000 47

073230 Tension gauges CORREX
flat feeler tip
The Correx tension gauge gives good results wherever small mechanical forces are to be measured.
Features:
Clockwise and anti-clockwise measurements
Double scale (g, cN, Pond)
Accuracy ±0.01 x (range + measuring value)
Trailing pointer to indicate maximum values, and flat probe
Appropriate accessories:
Calibration weights 073455
Package contents:
Delivered in own case.
Note:
*Without trailing pointer
Order ID Range Probe length
g/cN/Pond mm
073230.0100 0.3...3* 32
073230.0200 0.6...6* 32
073230.0300 2...15 32
073230.0400 3...30 32
073230.0500 5...50 32
073230.0600 10...100 32
073230.0700 15...150 32
073230.0800 25...250 32
073230.0900 50...500 47
073230.1000 100...1000 47
073230.1100 200...2000 47
