063587 Carbide gauge block
Tolerance class 0 - For calibration during production and in air-conditioned control labo-
ratories. Anti-magnetic, very resistant against oxydation and 10 times as much resistans as steel
gauges.
Package contents:
Delivered incl. calibration certificate.
With calibration certificate
Order ID Length Order ID Length Order ID Length Order ID Length
mm mm mm mm
063587.0010 0.5 063587.0320 1.21 063587.0630 1.70 063587.0940 16.0
063587.0020 1.0 063587.0330 1.22 063587.0640 1.80 063587.0950 16.5
063587.0030 1.001 063587.0340 1.23 063587.0650 1.90 063587.0960 17.0
063587.0040 1.002 063587.0350 1.24 063587.0660 2.0 063587.0970 17.5
063587.0050 1.003 063587.0360 1.25 063587.0670 2.5 063587.0980 18.0
063587.0060 1.004 063587.0370 1.26 063587.0680 3.0 063587.0990 18.5
063587.0070 1.005 063587.0380 1.27 063587.0690 3.5 063587.1000 19.0
063587.0080 1.006 063587.0390 1.28 063587.0700 4.0 063587.1010 19.5
063587.0090 1.007 063587.0400 1.29 063587.0710 4.5 063587.1020 20.0
063587.0100 1.008 063587.0410 1.30 063587.0720 5.0 063587.1030 20.5
063587.0110 1.009 063587.0420 1.31 063587.0730 5.5 063587.1040 21.0
063587.0120 1.01 063587.0430 1.32 063587.0740 6.0 063587.1050 21.5
063587.0130 1.02 063587.0440 1.33 063587.0750 6.5 063587.1060 22.0
063587.0140 1.03 063587.0450 1.34 063587.0760 7.0 063587.1070 22.5
063587.0150 1.04 063587.0460 1.35 063587.0770 7.5 063587.1080 23.0
063587.0160 1.05 063587.0470 1.36 063587.0780 8.0 063587.1090 23.5
063587.0170 1.06 063587.0480 1.37 063587.0790 8.5 063587.1100 24.0
063587.0180 1.07 063587.0490 1.38 063587.0800 9.0 063587.1110 24.5
063587.0190 1.08 063587.0500 1.39 063587.0810 9.5 063587.1120 25.0
063587.0200 1.09 063587.0510 1.40 063587.0820 10.0 063587.1130 30.0
063587.0210 1.10 063587.0520 1.41 063587.0830 10.5 063587.1140 40.0
063587.0220 1.11 063587.0530 1.42 063587.0840 11.0 063587.1150 50.0
063587.0230 1.12 063587.0540 1.43 063587.0850 11.5 063587.1160 60.0
063587.0240 1.13 063587.0550 1.44 063587.0860 12.0 063587.1170 70.0
063587.0250 1.14 063587.0560 1.45 063587.0870 12.5 063587.1180 75.0
063587.0260 1.15 063587.0570 1.46 063587.0880 13.0 063587.1190 80.0
063587.0270 1.16 063587.0580 1.47 063587.0890 13.5 063587.1200 90.0
063587.0280 1.17 063587.0590 1.48 063587.0900 14.0 063587.1210 100.0
063587.0290 1.18 063587.0600 1.49 063587.0910 14.5
063587.0300 1.19 063587.0610 1.50 063587.0920 15.0
063587.0310 1.20 063587.0620 1.60 063587.0930 15.5
063620 Steel ball set OPUS
Used to measure small internal tapers, internal annular grooves and throated worm wheels. The
precision of the steel balls is 20 µm (concernd to the nominal size). Each standard set of balls
contains a range of sizes, with three matched balls per size. Max. deviation of the form within a
set 1 µm.
With calibration certificate
Order ID Designation
063620.0100 Set of 75 measuring balls,
nominal diameter 1...25 mm
063620.0200 Set of 36 balls with nominal
size Ø 1.5...12.5 mm
063630 Planar glass TESA
For surface evenness and wring tests on parallel gauge blocks or other test pieces with similar
high-precision even surfaces.
Note:
Does not measure the parallelism of tested surfaces.
Package contents:
Delivered in own case.
Order ID Ø Thickness Evenness
mm mm µm
063630.0100 50 15 0.125
063630.0200 75 20 0.125
063640 Gauge block maintenance kit
We recommend this maintenance kit for protecting the surfaces of gauge blocks and making them
easier to wring. The contents consist of: 1 linen cloth, 1 chamois skin, 1 can corrosion protection
oil, 1 whetstone, 1 bristle brush, 1 grease brush.
Package contents:
Delivered in own case with application instructions.
Order ID 063640.0100
