Form/smooth/thread gauges Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
063547 Parallel gauge block FUTURO, ceramic
Tolerance class 0 - DIN EN ISO 3650 - These gauge blocks are used as factory or working stan-
dards in calibration labs and climate-controlled testing rooms for setting and calibrating
gauges and measuring devices. Ceramic is anti-magnetic, has low thermal conductivity and high
wear resistance compared to steel.
Package contents:
Delivered incl. calibration certificate.
Order ID Length Order ID Length Order ID Length
mm mm mm
063547.0410 0.50 063547.1760 7.00 063547.2030 18.50
063547.1000 1.00 063547.1770 7.50 063547.2040 19.00
063547.1010 1.0005 063547.1790 8.00 063547.2050 19.50
063547.1060 1.005 063547.1800 8.50 063547.2060 20.00
063547.1200 1.10 063547.1810 9.00 063547.2080 20.50
063547.1300 1.20 063547.1820 9.50 063547.2090 21.00
063547.1400 1.30 063547.1830 10.00 063547.2100 21.50
063547.1500 1.40 063547.1850 10.50 063547.2110 22.00
063547.1600 1.50 063547.1860 11.00 063547.2120 22.50
063547.1610 1.60 063547.1870 11.50 063547.2140 23.00
063547.1620 1.70 063547.1880 12.00 063547.2150 23.50
063547.1630 1.80 063547.1890 12.50 063547.2160 24.00
063547.1640 1.90 063547.1910 13.00 063547.2170 24.50
063547.1650 2.00 063547.1920 13.50 063547.2180 25.00
With calibration certificate 063547.1660 2.50 063547.1930 14.00 063547.2190 30.00
063547.1670 3.00 063547.1940 14.50 063547.2200 40.00
063547.1680 3.50 063547.1950 15.00 063547.2210 50.00
063547.1690 4.00 063547.1960 15.50 063547.2220 60.00
063547.1700 4.50 063547.1970 16.00 063547.2230 70.00
063547.1710 5.00 063547.1980 16.50 063547.2240 75.00
063547.1730 5.50 063547.1990 17.00 063547.2250 80.00
063547.1740 6.00 063547.2000 17.50 063547.2260 90.00
063547.1750 6.50 063547.2020 18.00 063547.2270 100.00
063581 Carbide gauge block set
Tolerance class 1 - For inspections during production. Tungsten carbide gauge blocks are anti-
magnetic, very resistant against oxydation and 10 times as much resistans as steel gauges.
Even in heavy-duty applications with tough working conditions (for ex. in the presence of grinding
swarf) the high surface hardness of around 1400 HV ensures that tungsten carbide gauge blocks
continue to have a very long service life.
Package contents:
Delivered incl. calibration certificate.
Order ID Number Order ID Number Order ID Number
063581.0100 32 063581.0300 76 063581.0500 103
063581.0200 47 063581.0400 88 063581.0600 112

063583 Carbide parallel gauge block set
Tolerance class 0 - For calibrations in production and in air-conditioned testing rooms.
Tungsten carbide gauge blocks are anti-magnetic, very resistant to oxidation, and about 10 times
more resistant to wear than steel.
Even in heavy-duty applications with tough working conditions (for example, in the presence of
grinding swarf) the high surface hardness of around 1400 HV ensures that tungsten carbide gauge
blocks continue to have a very long service life.
Package contents:
Delivered incl. calibration certificate.
Order ID Number Order ID Number Order ID Number
063583.0100 32 063583.0300 76 063583.0500 103
063583.0200 47 063583.0400 88 063583.0600 112
