057352 Hardness tester SAUTER HN-D
Hardness tester according to the Leeb method for mobile hardness testing of metals. This compact
device allows convenient handling with only one hand.
Selectable devices:
Leeb (HL)
Rockwell (HR B/C)
Vickers (HV)
Brinell HB)
Shore (HSD)
Features:
LCD display with background lighting
Compensation for the test direction (360°)
Internal rebound sensor D
Internal controller memory (500 measurement data)
Data output USB-PC
Accuracy: ±4 HLD
Housing dimensions (L x W x H) / 145 x 35 x 25 mm
Battery operation / power supply internal
Net weight approx. 70g
Package contents:
Delivered in sturdy carrying case incl. power supply and power cable.
Note:
Following a successful measurement (on Leeb device), the desired HRB / HRC / HV / HB / HSD hard-
ness unit can be selected. Unit conversion is performed automatically.
Test piece weight: min. 3 kg on solid base (sensor D)
Thinnest measurable layer: min. 8 mm (sensor D)
PC software for downloading the stored data - 057360.0190
* subject to material hardness and type
Order ID Range
057352.0010 20...68 HRC*
14...99 HRB*
19...650 HB*
83...976 HV*
27...99 HSD*
057354 Hardness tester SAUTER HMO
Hardness tester for mobile hardness testing of metals. This device offers a comprehensive range of
functions for professional applications. The innovative touchscreen allows comfortable and easy-
to-understand operation of the device.
Selectable units:
Leeb (HL)
Rockwell (HR-B/C),
Vickers (HV)
Brinell (HB),
Shore (HSD)
Tensile strengt (MPa)
Features:
LCD display with background lighting
Automatic sensor detection
Auto. compensation for the test direction (360°)
External rebound sensor type D
Internal controller memory (up to 800 sample groups at 99 single values)
Mini statistic function
Accuracy: 1% 800 HLD (± 8 HLD)
Dimensions (L x W x H) / 135 x 83 x 24 mm
Data output USB
External thermoprinter (infrared interface)
Net weight approx. 228 g
Package contents:
Delivered in sturdy carrying case including display unit, external rebound sensor D, thermoprinter
(infrared interface), test block, power supply and power cable.
Note:
Following a successful measurement (on Leeb device), the desired HRB / HRC / HV / HB / HSD hard-
ness unit can be selected. Unit conversion is performed automatically.
Test piece weight: min. 3 kg on solid base (sensor D)
Thinnest measurable layer: min. 8 mm (sensor D)
* Measuring range subject to material hardness / type
Order ID Range
057354.0010 20...68 HRC*
14...99 HRB*
19...650 HB*
83...976 HV*
27...99 HSD*
