Rules / tape measures / distance measuring Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
058560 Stainless steel rule
1/1 mm - 1/1 mm
Flexible stainless steel construction, hardened and matt chrome-plated. Accuracy to DIN 866 B
standard. Precise graduation top 1/1 mm, bottom 1/1 mm. 1/1 mm - 1/1 mm
Order ID Length Profile Order ID Length Profile
mm mm mm mm
058560.0100 150 13 x 0.5 058560.0600 1000 35 x 1.3
058560.0200 200 15 x 0.5 058560.0700 1500 35 x 1.3
058560.0300 300 15 x 0.5 058560.0800 2000 35 x 1.3
058560.0400 500 19 x 0.5 058560.0900 3000 35 x 1.3
058560.0500 1000 20 x 0.5
058570 Stainless steel rule
1/1 mm - 1/2 mm
Flexible stainless steel design, hardened and matt chrome-plated. Accuracy to DIN 866 B standard.
Precise graduation top 1/1 mm, bottom 1/2 mm 1/1 mm - 1/2 mm
Order ID Length Profile Order ID Length Profile
mm mm mm mm
058570.0100 150 13 x 0.5 058570.0500 1000 20 x 0.5
058570.0200 200 15 x 0.5 058570.0600 1500 35 x 1.3
058570.0300 300 15 x 0.5 058570.0700 2000 35 x 1.3
058570.0400 500 19 x 0.5
058580 Stainless steel rule
1/16“ - 1/1 mm
Flexible stainless steel design, hardened and matt chrome-plated. Accuracy to DIN 866 B standard.
Precise graduation top 1/16“, bottom 1/1 mm.
1/16“ - 1/1 mm
Order ID Length Profile Order ID Length Profile
mm mm mm mm
058580.0100 300 15 x 0.3 058580.0300 1000 20 x 0.6
058580.0200 500 20 x 0.6
058590 Stainless steel rule
1/1 mm - 1/1 mm
Stainless steel design, matt (anti-glare), deep-etched scales, black, chrome-plated. Accuracy to DIN
866 B standard. Precise graduation top 1/1 mm, bottom 1/1 mm. 1/1 mm - 1/1 mm
Order ID Length Profile Order ID Length Profile
mm mm mm mm
058590.0200 150 13 x 0.3 058590.0800 1000 18 x 0.5
058590.0300 200 13 x 0.3 058590.0900 1500 18 x 0.5
058590.0500 300 13 x 0.3 058590.1000 2000 18 x 0.5
058590.0700 500 18 x 0.5
058600 Stainless steel rule
1/2 mm - 1/1 mm
Stainless steel design, matt (anti-glare), deep-etched scales, black, chrome-plated. Accuracy to DIN
866 B standard. Precise graduation top 1/2 mm, bottom 1/1 mm. 1/2 mm - 1/1 mm
Order ID Length Profile Order ID Length Profile
mm mm mm mm
058600.0200 150 13 x 0.3 058600.0800 1000 18 x 0.5
058600.0300 200 13 x 0.3 058600.0900 1500 18 x 0.5
058600.0500 300 13 x 0.3 058600.1000 2000 18 x 0.5
058600.0700 500 18 x 0.5

058610 Stainless steel rule
right to left 1/1 mm 1/1 mm
Stainless steel design, matt (anti-glare), deep-etched scales, black, chrome-plated. Accuracy to DIN
866 B standard. Precise graduation right to left, top 1/1 mm, bottom 1/1 mm.
1/1 mm - 1/1 mm
Order ID Length Profile Order ID Length Profile
mm mm mm mm
058610.0200 150 13 x 0.3 058610.0800 1000 18 x 0.5
058610.0300 200 13 x 0.3 058610.0900 1500 18 x 0.5
058610.0500 300 13 x 0.3 058610.1000 2000 18 x 0.5
058610.0700 500 18 x 0.5
058630 Stainless steel rule
1/2 mm - 1/1 mm (1/1 mm - 1/1 mm)
Stainless steel design, matt chrome-plated, black scales, deepened and etched. Accuracy to DIN
866 B standard.
Order ID Length Profile Version 1/2 mm - 1/1 mm
mm mm
058630.0100 300 30 x 1 Precise graduation: 1/2 mm - 1/1 mm
058630.0200 500 30 x 1 Precise graduation: 1/2 mm - 1/1 mm
058630.0400 1500 35 x 1.3 Precise graduation: 1/1 mm - 1/1 mm
058630.0500 2000 35 x 1.3 Precise graduation: 1/1 mm - 1/1 mm

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 285
