Rules / tape measures / distance measuring Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
059160 Telescoping metre scale Messfix
Telescoping gauge for horizontal and vertical inside measurements with reading 1 mm. The
extended length can be read directly in the read-off window.
Order ID Length Range Weight
m m kg
059160.0100 3 0.7...3.00 1.1
059160.0200 4 0.86...4.00 1.4
059160.0300 5 1.07...5.00 1.7
059410 C tape measure INOX
Stainless steel tape measure - With accuracy to DIN 866, for measuring outside diameters.
Features:
mm graduation
Vernier reading to 0.05 mm
Other sizes on request
Order ID Range Ø Tape width Order ID Range Ø Tape width
mm mm mm mm
059410.0100 15...115 12 059410.0300 200...330 12
059410.0200 100...230 12 059410.0400 300...620 12
059420 C tape measure
Steel tape for measuring the diameters and circumferences of round objects.
Features:
Graduation mm
Vernier scale 0.1 mm
Accuracy class II
Order ID Circumference Range Ø Tape width
mm mm mm
059420.0100 60...950 20...300 16
059420.0200 940...2200 300...700 16
059420.0300 2190...3460 700...1100 16
059420.0400 3450...4720 1100...1500 16
059420.0500 4710...5980 1500...1900 16
059420.0600 5960...7230 1900...2300 16
059430 Steel measuring tape, self-adhesive
Adhesive measuring tape - Steel, painted white with mm graduation, self-adhesive. Suitable as
an aid for applications in mechanical engineering, on workbenches, etc.
Other lengths/designs on request
Order ID Length Tape width Version
m mm
059430.0040 1 13 left to right
059430.0070 2 13 left to right
059430.0100 5 13 left to right
059430.0200 10 13 left to right
059430.0300 15 13 left to right
059430.1040 1 13 right to left
059430.1070 2 13 right to left
059430.1100 5 13 right to left
059430.1200 10 13 right to left
059430.1300 15 13 right to left

059450 Tape rule FUTURO
mm / mm
TRI-MATIC / EC Class I - Precision version with belt clip, continuous mm graduation, steel tape
painted yellow, anti-reflective coating, automatic tape retraction, backstop, and chrome-plated
plastic housing.
Order ID Length Tape width
m mm
059450.0100 3 13
059450.0200 5 19

288 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
