Hardness / coating thickness / ultrasound Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
056880 Accessories ECHOMETER
Order ID Designation
056880.0100 Standard probe, DSE 10.4/6 PB4 (4 MHz) / 1.2...250 mm
056880.0200 Grip sleeve for standard probe, DSE 10.4/6 PB4
056880.0300 Vulcolan film for standard probe (10 pcs), DSE 10.4/6 PB4
056880.0400 Miniature probe for ECHOMETER 1076, DSE 4.2/4 PB10 (10 MHz) / 0.5...25 mm
056880.0500 Grip sleeve for miniature probe DSE 4.2/4 PB10
056880.0700 Low frequency probe for ECHOMETER 1076, DSE 18/25 PB2 (2 MHz) / 5...400
mm
056880.0800 Grip sleeve for low frequency probe DSE 18/25 PB2
056880.0900 Vulcolan film for low frequency probe (10 pcs), DSE 18/25 PB2
056880.1000 Battery set NiMH (2x 1.2V AA)
056880.1100 Quick charger 230 V for 4 NiMH batteries
056880.1200 Leather case
056880.1300 Couplant gel ECHOTRACE
(100 ml tube)
056880.1305 Coupling material ECHOFLUID 100 ml bottle
056880.1310 Coupling material ECHOTRACE 500 ml bottle
056880.1315 Coupling material ECHOFLUID 1000 ml bottle
056880.1400 Connecting cable RS 232C (PC)
056880.1405 Adapter cable USB incl. driver CD, RS-232 - USB

056882 Wall thickness gauge
PocketMike - Universally usable ultrasound wall thickness gauge with integrated test head. Easy
usage via four keys with automatic ON block offset compensation.
Features:
Integrated transducer, 5 MHz
One hand use
Body of stainless steel
Automatic Zero-Point-adjustment
Diplay lighting
Adjustment of known wallthickness possible
Adjustment of known speed of sound
Plastic foil keyboard
Exchangeable probes
Selectable measurement units
Dimensions Ø 35 x 100 mm
Example application
Package contents:
Delivered in transport case incl. carrying strap, interchangeable test head, coupling means, opera-
ting manual and factory certificate.
Appropriate batteries:
1 pieces 055050.0300 - LR6 / 1.5 V (AA) (included in scope of delivery).
Order ID Range Resolution Protection class Weight
mm mm kg
056882.0100 1...250 0.01 / 0.1 IP67 0.2
057252 Shore Hardness tester SAUTER HB
Handy Shore hardness tester with friction pointer.
Designs:
057252.0010 Shore A: soft rubber, elastomers, natural rubber, neoprene, cast resin, polyester,
soft PVC, leather.
057252.0020 Shore A/O: foamed material, sponges.
057252.0030 Shore D: hard rubber, acrylic glass, press rollers, Formica, heart thermoplastics, po-
lyester.
Features:
Max mode: acquires the peak value
Point mode: indicates the stable measured value
Mountable on test stands
Accuracy: 3% of max
Package content:
Supplied in high quality wooden box.
Note:
We propose to use the device together with a set of calibration plates (157315). The calibration
plates can optionally be ordered with ISO calibration.
Order ID Type Range Test item thickness min. for materials
mm
057252.0010 A 100 HA 6 soft
057252.0020 A/O 100 HC 6 soft
057252.0030 D 100 HD 6 hard
