Optical viewing tools / measuring instr.  Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
      051228   Magnifying lamp LUXO KFM LED
      Magnifying lamp with 2 semi-circular LED modules. The flexibility of the joint between lamp head
      and arm makes exact positioning easy.
      Designs:
      051228.0100...051228.0200: Standard
      051228.0300...051228.0400: ESD
      Features:
      Light source LED 1 x 11 W
      Glass lens
      Package contents:
      Delivered with table clamp.
                                                                          051228.0100
      Order ID                       051228.0100   051228.0200    051228.0300   051228.0400
      Type                          KFM LED / 3 dpt  KFM LED / 5 dpt  KFM LED ESD / 3 dpt  KFM LED ESD / 5 dpt
      Magnification                    1.75 x         2.25 x        1.75 x        2.25 x
      Lens size     mm                 Ø 115          Ø 115         Ø 115         Ø 115
      Focal length  mm                  330           200           330            200
      Luminous flux  lm                 900           900           900            900
      Light temperature  K              4000          4000          4000          4000
      Arm lengths   mm                500 + 550     500 + 550     500 + 550      500 + 550
      Colour                            white         white         black         black
      Weight        kg                  4.3           4.3            4.3           4.3
      Version                          Standard      Standard       ESD            ESD
      051275   LED magnifier lamp SCHWEIZER
      Tech-Line
      Power-LED - Scratchproof, solvent-resistant silicate glass lenses. The magnifying glass head is open
      towards the front, allowing a very comfortable working position, because the field of view is not
      constricted by the edge of the magnifying glass. It is easy to position objects because it is possible
      to see them by bypassing the lens (situational awareness).
      Features:
      Bright, high-contrast illumination
      Life time LED 25000 h
      Very low power consumption
      Stable arm of aluminium profile
      inside springs
      Package contents:                                                   051275.0100
      Delivered with table clamp (18...74 mm opening width).
      Order ID                     051275.0100      051275.0200
      Type                         2 x / Ø 120     1.75 x / Ø 202
      Magnification                   2 x             1.75x
      Lens size        mm            Ø 120            Ø 202
      Light temperature  K                            6000
      Arm lengths      mm          500 + 500         500 + 500
      Colour                         silver           silver
      Weight           kg             3.3              4.9
      Version                    Power-LED 3 x 1 W  Power-LED 6 x 1 W

                                                                          051275.0200
      051292   Accessories FUTURO
      for FUTURO LTS magnifier lamp
      Order ID  Designation
      051292.0100 Replacement halogen lamp 100 W / 230 V
      051292.0200 Table clamp 0...60 mm

      051300   Optics cleaning set
      Lint free, very soft special drying cloth together with a gentle cleaning solution for all lenses and
      magnifiers made of glass or plastic.
      Order ID                       Contents
                                       ml
      051300.0100                      30
      051300.0200                      35



                                                                          051300.0200
