Page 255 - Benma | Blue book 5.0

Optical viewing tools / measuring instr. Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
051190 Magnifier lamp WALDMANN SNL 319
This magnifying lamp allows the light characteristic to be varied. Either low-shadow light or sha-
dow-forming light to accentuate 3-D structures can be selected. This magnifying lamp is characte-
rized by extremely high light intensity, a large inspection field and low energy consumption.
Features:
Compact fluorescent bulb TC-S / TC-SEL / 3 x 9 W
Swivelling glass lens
Plastic case
3-D ball-joint head for individual adjustment
Spring-held articulation joints
Multiposition switch in lamp head SNL / SNLE 319
Package contents:
Delivered with fluorescent bulb and screw-on base.
Appropriates accessories:
Accessories 051200
Fluorescent bulb 9W 462020.0200
Note:
The magnifier lamp can be bolted directly to the top of a table by means of the holes (4 through
holes, Ø 6 mm) in the screw-on base. If necessary, a table clamp 051200 can be ordered.
Order ID 051190.0100 051190.0200 051190.0300
Type SNL 319 / 3dpt SNLE 319 / 3 dpt SNL 319A ESD /
3 dpt
Magnification 1.75x 1.75x 1.75x
with attached 2.75x 2.75x 2.75x
magnifier
Lens size mm 175 x 105 175 x 105 175 x 105
Reflector size mm 298 x 194 x 64 298 x 194 x 64 298 x 194 x 64
Illuminance lx 4250...6095 4250...6095 4250...6095
Light temperature K 4000 4000 4000
Arm lengths mm 400 + 430 400 + 430 400 + 430
Colour grey grey black
Weight kg 4.5 4.0 4.4
Version Standard version With electronic ESD version
ballast
051200 Accessories WALDMANN
Order ID Designation
RLL 122T RLL Q63 RLLQ 48 SNL 319

051200.0100 Attached magnifier (for RLL 122 T) 4 dpt / Ø 112

051200.0200 Attached magnifier (for SNL) 4 dpt / 50x100

051200.0300 Attached magnifier ESD (for SNL) 4 dpt / 50x100

051200.0500 Table clamp 65...135 mm

051200.0600 Table clamp 0...140 mm

051200.0700 Table clamp ESD 0...65 mm
