Optical viewing tools / measuring instr. Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
051075 Measuring magnifier with light
Package contents:
Delivered in case including measuring plate with 0...20 mm scale, 0.1 mm graduation
(051080.0200) without batteries..
Appropriate batteries:
2 pieces 055050.0200 - LR14 / 1.5 V (C) (NOT included in scope of delivery).
Order ID Magnification
051075.0100 7x
051080 Measuring plate
Suitable for 051075.
Features:
Plate Ø 26 mm
Scale 0...20 mm
Graduation 0.1 mm
Order ID 051080.0200
051080.0200
051100 Linen tester SCHWEIZER Tech-Line
Aplanar magnifying glass, ground optical silicate glass for a sharp edged image. Leather case as
option.
Designs:
051100.0100: with scale 10 mm / 0.1 mm
051100.0200: without scale
Package contents:
Delivered in transport packaging.
Appropriate accessories:
051105 Leather case
Order ID Magnification Section Lens Ø Version
mm mm
051100.0100 8x 20 x 20 16.3 with scale 10 mm / 0.1 mm
051100.0200 051100.0200 8x 20 x 20 16.3 without scale
051105 Leather case
For strand counter 051100.
Order ID 051105.0100

051120 Measuring magnifier F+C
For exact measurement of: Line thicknesses, distances on plans and drawings, holes, hole spacing,
profile gauges, facets, angles etc.
The magnifier is placed directly onto the object to be measured and the length can then easily
be read off the precision scale on the bottom. Focusing makes it possible to adapt to the user‘s
individual vision.
Features measuring magnifier:
Metal alloy case
Glass eyepiece
Features reticule:
Scale 0...15 mm / graduation 0.1 mm
Radii: 0.5...6.0 mm / pitch 0.5 mm
Angles 0°...90° / pitch 5°
Package contents:
Delivered in break-proof plastic case.
Appropriate accessories:
Additional reticules 051125
Order ID 051120.0200
Magnification 8x
051125 Reticules F+C
051125.0200:
Scale 0...15 mm; scale division 0.1 mm
Radii 0.5...6 mm
Angle 0...90°
051125.0300:
Upper scale: 0...15 mm, scale division 0.1 mm
051125.0200 051125.0300
Bottom scale: 0...0.6“, scale division 0.005“
Order ID 051125.0200 051125.0300
