Optical viewing tools / measuring instr. Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
051041 Lenses for clip-on lens ESCHENBACH
Designs:
051041.0100...051041.0400: binocular
051041.0500...051041.0600: monocular
Order ID Magnification Dioptres Focal length Version
mm
051041.0100 1.7x 2.5 400 binocular 051041.0100 051041.0500
051041.0200 2x 2.5 250 binocular ...0400 ...0600
051041.0300 2.5x 5.0 180 binocular
051041.0400 3x 7.5 130 binocular
051041.0500 4x 16 55 monocular
051041.0600 7x 28 32 monocular
051042 Magnifying spectacles ESCHENBACH
MaxDetail
With MaxDetail you have both hands free for fine work at close distances. These spectacles have a
double lens system which magnifies for better reading and working. MaxDetail is also suitable for
spectacle wearers, because it can provide correction of ±3 dioptres (right and left can be adjusted
independently of each other).
Order ID Magnification Working distance
mm
051042.0100 2.0 x 400

051044 Reading glasses ESCHENBACH
These reading glasses are for emergencies as replacement or extra glasses for close-up vision.
Features:
Rimless reading glasses
Metal/plastic frame Model for ladies
Order ID Model Dioptres Colour Order ID Model Dioptres Colour
051044.0100 Women 1.0 Silver 051044.0700 Men 1.0 Gun metal
051044.0200 Women 1.5 Silver 051044.0800 Men 1.5 Gun metal
051044.0300 Women 2.0 Silver 051044.0900 Men 2.0 Gun metal
051044.0400 Women 2.5 Silver 051044.1000 Men 2.5 Gun metal Model for gentlemen
051044.0500 Women 3.0 Silver 051044.1100 Men 3.0 Gun metal
051044.0600 Women 3.5 Silver 051044.1200 Men 3.5 Gun metal
051060 Measuring magnifier
For measuring lengths, angles, diameters, line thicknesses, thread pitches, etc.
Features:
Achromatic (very transparent and distortion-free)
4 lenses
Measuring plate, Ø 35 mm
exchangeable
Package contents:
Delivered in case including measuring plate with 0...20 mm scale, 0.1 mm graduation
(051065.0400).
Appropriate accessories:
Other measuring plates 051065
Order ID Magnification Size
mm
051060.0100 10x Ø 45 x 45

051065 Measuring plate
Holder Ø 35 mm, suitable for 051060.

051065.0100 051065.0200 051065.0300 051065.0400

051065.0500 051065.0600 051065.0700
Order ID Designation
051065.0100 scale, grid, radii, angles
051065.0200 scale, radii, angles, circles
051065.0300 grid, circles
051065.0400 scale 0...20 mm / 0.1 mm
051065.0500 radii, angles
051065.0600 Thread pitch metric, 0.25...1.0 mm
051065.0700 thread pitch inch 8...50

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 245
