3D Probe elements Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
046830 M5 Sensor insert NÜSSLER
Carbide shank, ruby ball / type TB
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
046830.0010 3.0 2.0 25.0 15.0 6 11.0
046830.0020 3.0 2.0 33.5 23.5 6 11.0
046830.0030 3.0 2.0 50.0 40.0 7 11.0
046830.0040 3.0 2.0 58.0 48.0 8 11.0
046830.0050 4.0 2.0 33.5 23.5 7 11.0
046830.0060 4.0 2.0 64.0 54.0 8 11.0
046830.0070 5.0 3.5 50.0 40.0 11 11.0
046830.0080 5.0 3.5 53.0 43.0 12 11.0
046830.0090 5.0 3.5 75.0 65.0 15 11.0
046830.0100 6.0 3.5 54.0 44.0 12 11.0
046830.0110 7.0 3.5 55.0 45.0 13 11.0
046830.0120 8.0 6.0 63.5 50.5 26 11.0
046830.0130 8.0 6.0 74.0 61.0 32 11.0
046830.0140 8.0 6.0 75.0 62.0 32 11.0
046830.0150 8.0 6.0 100.0 87.0 42 11.0
046830.0160 8.0 6.0 114.5 101.5 46 11.0
046830.0170 9.0 6.0 64.5 51.5 27 11.0
046830.0180 10.0 6.0 65.5 52.5 27 11.0
046830.0190 10.0 6.0 118.0 105.0 49 11.0
046830.0200 8.0 6.0 63.5 41.5 42 18.0
046830.0210 8.0 6.0 114.5 92.5 63 18.0
046830.0220 9.0 6.0 64.5 42.5 42 18.0
046830.0230 10.0 6.0 65.5 43.5 43 18.0
046840 M5 Sensor insert NÜSSLER
Ceramic shank, ruby ball / type KE
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
046840.0010 5.0 3.6 53.0 43.0 7 11.0
046840.0020 6.0 3.6 54.0 44.0 7 11.0
046840.0030 7.0 3.6 55.0 45.0 8 11.0
046840.0040 8.0 6.3 63.5 50.5 12 11.0
046840.0050 8.0 6.3 114.5 101.5 18 11.0
046840.0060 9.0 6.3 64.5 51.5 13 11.0
046840.0070 10.0 6.3 65.5 52.5 13 11.0
046840.0080 8.0 6.3 63.5 41.5 32 18.0
046840.0090 8.0 6.3 114.5 92.5 38 18.0
046840.0100 9.0 6.3 64.5 42.5 32 18.0
046840.0110 10.0 6.3 65.5 43.5 33 18.0

046850 M5 Sensor insert NÜSSLER
Shank carbon fibre, ruby ball / type CA
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
046850.0010 4.0 3.0 33.5 23.5 5 11.0
046850.0020 5.0 3.0 53.0 43.0 6 11.0
046850.0030 6.0 4.0 54.0 44.0 6 11.0
046850.0040 7.0 4.0 55.0 45.0 7 11.0
046850.0050 8.0 6.0 63.5 50.0 8 11.0
046850.0060 8.0 6.0 114.5 101.5 11 11.0
046850.0070 9.0 6.0 64.5 41.5 9 11.0
046850.0080 10.0 6.0 65.5 52.5 9 11.0
046850.0090 8.0 6.0 63.5 41.5 29 18.0
046850.0100 8.0 6.0 114.5 92.5 31 18.0
046850.0110 9.0 6.0 64.5 42.5 29 18.0
046850.0120 10.0 6.0 65.5 43.5 30 18.0
046890 T-Sensor insert NÜSSLER
Carbide shank, Ø 3 mm, ruby ball / type H
Order ID dk ds MD L Weight
mm mm mm mm g
046890.0010 1.0 3.0 10.0 50.0 3
046890.0020 1.0 3.0 10.0 100.0 5
046890.0030 2.0 3.0 20.0 50.0 3
046890.0040 2.0 3.0 20.0 100.0 5

046910 Sensor insert NÜSSLER
Carbide shank, Ø 3 mm, ruby ball / type N
Order ID dk ds L Weight Order ID dk ds L Weight
mm mm mm g mm mm mm g
046910.0010 5.0 3.0 45.0 6.0 046910.0040 8.0 3.0 44.0 6.5
046910.0020 6.0 3.0 73.0 7.5 046910.0050 8.0 3.0 73.0 7.5
046910.0030 6.0 3.0 103 10.5 046910.0060 8.0 3.0 103.0 10.5
