3D Probe elements Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
046080 M3 Sensor pin holder NÜSSLER
Steel / 5-way / type HF
Order ID D L ML d1 Weight
mm mm mm mm g
046080.0010 10 x 10 13.0 5.5 4.0 2.4

046090 M3 Sensor joint NÜSSLER
Steel, rotating
Order ID L d1 D Weight
mm mm mm g
046090.0010 17.0 M3 4 1.5

045680.0020
046250 M4 Sensor insert NÜSSLER
Carbide shank, ruby ball / type A
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
046250.0010 0.25 0.2 13 2.5 0.4 5
046250.0020 0.3 0.2 13 2.5 0.4 5
046250.0030 0.4 0.3 13 2.5 0.4 5
046250.0040 0.5 0.3 13 2.5 0.4 5
046250.0050 0.6 0.4 13 2.5 0.4 5
046250.0060 0.6 0.4 15 4.5 0.4 5
046250.0070 0.7 0.4 13 2.5 0.4 5
046250.0080 0.7 0.4 15 4.5 0.4 5
046250.0090 0.8 0.6 13 2.5 0.4 5
046250.0100 0.8 0.6 15 4.5 0.4 5
046250.0110 0.9 0.6 13 2.5 0.4 5
046250.0120 0.9 0.6 15 4.5 0.4 5
046250.0130 1.0 0.8 13 2.5 0.4 5
046250.0140 1.0 0.8 15 4.5 0.4 5
046260 M4 Sensor insert NÜSSLER
Carbide shank, ruby ball / type B
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
046260.0010 1.0 0.7 15.5 7.5 1.7 5
046260.0020 1.0 0.7 20.5 12.5 1.7 5
046260.0030 2.0 1.2 16.0 8.0 1.7 5
046260.0040 2.0 1.2 26.0 18.0 1.8 5
046260.0050 2.0 1.2 36.0 28.0 1.9 5
046260.0060 2.0 1.2 41.0 33.0 2.0 5
046260.0070 3.0 2.0 31.5 23.5 2.4 5
046260.0080 3.0 2.0 41.5 33.5 2.6 5
046260.0090 3.0 2.0 51.5 43.5 2.9 5
046260.0100 4.0 2.0 32.0 24.0 2.9 5
046260.0110 4.0 2.0 42.0 34.0 3.4 5
046260.0120 4.0 2.0 52.0 44.0 3.8 5
046260.0130 5.0 2.5 32.5 24.5 3.0 5
046260.0140 5.0 2.5 42.5 34.5 3.5 5
046260.0150 5.0 2.5 52.5 44.5 3.9 5
046260.0160 6.0 3.0 33.0 25.0 3.2 5
046260.0170 6.0 3.0 43.0 35.0 3.7 5
046260.0180 6.0 3.0 53.0 45.0 4.1 5
046270 M4 Sensor insert NÜSSLER
Steel shank, ruby ball / type C
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
046270.0010 2.0 1.3 16.0 10.0 1.3 5
046270.0020 2.5 1.5 21.0 15.0 1.3 5
046270.0030 3.0 2.0 21.5 15.5 1.5 5
046270.0040 4.0 2.4 22.0 16.0 1.7 5
046270.0050 6.0 3.0 28.0 22.0 2.6 5

220 Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch
