3D Probe elements Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
045850 M3 Sensor insert NÜSSLER
Carbide shank, ruby ball / type A
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
045850.0010 0.25 0.2 11.0 2.5 0.4 4
045850.0020 0.3 0.2 11.0 2.5 0.4 4
045850.0030 0.4 0.3 11.0 2.5 0.4 4
045850.0040 0.5 0.3 11.0 2.5 0.4 4
045850.0050 0.6 0.4 11.0 2.5 0.4 4
045850.0060 0.6 0.4 13.0 4.5 0.4 4
045850.0070 0.7 0.4 11.0 2.5 0.4 4
045850.0080 0.7 0.4 13.0 4.5 0.4 4
045850.0090 0.8 0.6 11.0 2.5 0.4 4
045850.0100 0.8 0.6 13.0 4.5 0.4 4
045850.0110 0.9 0.6 11.0 2.5 0.4 4
045850.0120 0.9 0.6 13.0 4.5 0.4 4
045850.0130 1.0 0.8 11.0 2.5 0.4 4
045850.0140 1.0 0.8 13.0 4.5 0.4 4
045860 M3 Sensor insert NÜSSLER
Carbide shank, ruby ball / type B
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
045860.0010 1.0 0.7 10.5 4.5 0.7 4
045860.0020 1.0 0.7 15.5 7.5 0.7 4
045860.0030 1.0 0.7 20.5 12.5 0.7 4
045860.0040 1.5 0.7 16.0 8.0 0.6 4
045860.0050 1.5 0.7 21.0 13.0 0.6 4
045860.0060 1.5 1.0 31.0 23.0 1.0 4
045860.0070 2.0 1.0 16.0 8.0 0.7 4
045860.0080 2.0 1.0 21.0 13.0 0.7 4
045860.0090 2.0 1.0 26.0 18.0 0.8 4
045860.0100 2.0 1.0 31.0 23.0 0.9 4
045860.0110 2.0 1.0 36.0 28.0 0.9 4
045860.0120 2.0 1.0 41.0 33.0 1.0 4
045860.0130 2.5 1.0 16.0 8.0 0.7 4
045860.0140 2.5 1.0 21.0 13.0 0.7 4
045860.0150 2.5 1.5 31.0 23.0 1.3 4
045860.0160 2.5 1.5 41.0 33.0 1.5 4
045860.0170 3.0 1.5 31.5 23.5 1.4 4
045860.0180 3.0 1.5 36.5 28.5 1.5 4
045860.0190 3.0 1.5 41.5 33.5 1.6 4
045860.0200 3.0 1.5 46.5 38.5 1.8 4
045860.0210 3.0 1.5 51.5 43.5 1.9 4
045860.0220 4.0 2.0 32.0 24.0 1.9 4
045860.0230 4.0 2.0 37.0 29.0 2.1 4
045860.0240 4.0 2.0 42.0 34.0 2.4 4
045860.0250 4.0 2.0 47.0 39.0 2.6 4
045860.0260 4.0 2.0 52.0 44.0 2.8 4
045860.0270 5.0 2.0 32.5 24.5 2.0 4
045860.0280 5.0 2.0 37.5 29.5 2.3 4
045860.0290 5.0 2.0 42.5 34.5 2.5 4
045860.0300 5.0 2.0 47.5 39.5 2.7 4
045860.0310 5.0 2.0 52.5 44.5 2.9 4
045860.0320 6.0 2.0 33.0 25.0 2.2 4
045860.0330 6.0 2.0 39.0 30.0 2.4 4
045860.0340 6.0 2.0 43.0 35.0 2.7 4
045860.0350 6.0 2.0 48.0 40.0 2.9 4
045860.0360 6.0 2.0 53.0 45.0 3.1 4
045870 M3 Sensor insert NÜSSLER
Carbide shank, ruby ball / type BS
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
045870.0010 0.5 0.3 21.0 2.5 1.0 4
