3D Probe elements Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
045560 M2 L-Sensor insert NÜSSLER
Carbide shank, ruby ball / type LT
Order ID dk d1 MR L Weight D
mm mm mm mm g mm
045560.0010 1.0 0.6 6.0 15.0 0.4 3
045560.0020 2.0 1.0 12.0 20.0 0.9 3

045570 M2 Ball sensor insert NÜSSLER
Steel shank, ceramic ball / type KK
Order ID dk L D Weight
mm mm mm g
045570.0010 8.0 10.0 3 1.1
045570.0020 10.0 11.0 3 1.7

045575 M2 Ball sensor insert NÜSSLER
Steel shank, ceramic ball / type HKE
Version with hollow ball.
Order ID dk L D Weight
mm mm mm g
045575.0010 18.0 16.0 3 4.6
045575.0020 24.0 19.0 3 8.9
045575.0030 30.0 22.0 3 13.1

045580 M2 Ball sensor insert NÜSSLER
Steel shank, ceramic ball / type HKz
Version with hollow ball and MR thread on end.
Order ID dk d1 L Weight D
mm mm mm g mm
045580.0010 18.0 M2 16.0 4.6 3
045580.0020 30.0 M2 22.0 13.1 3
045590 M2 Spherical washer sensor insert NÜSSLER
Carbide shank, ceramic washer / type KSK
Order ID dk d1 L Weight H D
mm mm mm g mm mm
045590.0010 5.0 1.5 20.0 0.7 0.5 3
045590.0020 10.0 2.0 25.0 1.4 0.8 3
045590.0030 14.0 2.0 25.0 1.5 1.0 3

045595 M2 Spherical washer sensor insert NÜSSLER
Steel shank, ceramic washer / type KSE
Order ID dk d1 L Weight H D
mm mm mm g mm mm
045595.0010 15.0 M2 4.0 0.9 1.0 5
045595.0020 20.0 M2 4.0 1.5 1.0 5

045600 M2 Spherical washer sensor insert rotatable NÜSSLER
Steel shank, steel washer / type KSD
Order ID dk d1 L Weight h1 H D
mm mm mm g mm mm mm
045600.0010 18.0 M2 12.0 2.8 2.5 4.0 5
045600.0020 25.0 M2 12.0 3.9 2.5 4.0 5
045600.0030 40.0 M2 12.0 11.0 4.0 6.0 5

045610 M2 Star sensor insert rotatable NÜSSLER
Carbide shank, ruby ball / type K
Order ID dk ds MD d1 L Weight D
mm mm mm mm mm g mm
045610.0010 1.0 3.5 12.0 0.6 5 0.5 6
045610.0020 1.0 3.5 16.0 0.6 5 0.6 6
045610.0030 2.0 3.5 20.0 1.0 5 1.1 8
045610.0040 2.0 3.5 30.0 1.0 5 1.2 8

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 213
