3D Probe elements Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
045430 M2 Sensor insert NÜSSLER
Steel shank, ruby ball / type C
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
045430.0010 1.0 0.7 10.5 5.0 0.3 3
045430.0020 1.5 1.0 11.0 6.0 0.3 3
045430.0030 2.0 1.2 11.0 7.0 0.3 3
045430.0040 2.0 1.2 16.0 12.0 0.3 3
045430.0050 2.0 1.4 21.0 15.0 0.3 3
045430.0060 2.5 1.5 11.0 7.0 0.3 3
045430.0070 2.5 1.5 21.0 17.0 0.4 3
045430.0080 3.0 2.0 11.5 8.0 0.4 3
045430.0090 3.0 2.0 21.5 18.0 0.6 3
045430.0100 4.0 2.4 12.0 9.0 0.5 3
045430.0110 4.0 2.4 22.0 19.0 0.9 3
045440 M2 Sensor insert NÜSSLER
Steel shank, ruby ball / type D
Order ID dk L D Weight
mm mm mm g
045440.0010 5.0 12.5 3 0.7
045440.0020 5.0 27.5 3 1.6
045440.0030 6.0 13.0 3 0.9
045440.0040 6.0 28.0 3 1.7
045440.0050 8.0 14.0 3 1.3
045440.0060 8.0 29.0 3 1.9

045450 M2 Sensor insert NÜSSLER
Ceramic shank, ruby ball / type KE
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
045450.0010 3.0 2.0 51.5 41.5 1.4 3
045450.0020 4.0 2.0 42.0 32.0 1.5 3
045450.0030 4.0 2.0 52.0 42.0 1.6 3
045450.0040 5.0 2.0 32.5 22.5 1.5 3
045450.0050 5.0 2.0 42.5 32.5 1.6 3
045450.0060 5.0 2.0 52.5 42.5 1.6 3
045450.0070 6.0 2.0 33.0 23.0 1.6 3
045450.0080 6.0 2.0 43.0 33.0 1.8 3
045450.0090 6.0 2.0 53.0 43.0 1.8 3
045460 M2 Sensor insert NÜSSLER
Shank carbon fibre, ruby ball / type CA
Order ID dk d1 L ML Weight D
mm mm mm mm g mm
045460.0010 4.0 3.0 42.0 32.0 0.7 3
045460.0020 4.0 3.0 52.0 42.0 0.7 3
045460.0030 4.0 3.0 52.0 42.0 0.7 3
045460.0040 5.0 3.0 32.5 22.5 0.7 3
045460.0050 5.0 3.0 42.5 32.5 0.7 3
045460.0060 5.0 3.0 52.5 42.5 0.9 3
045460.0070 6.0 3.0 33.0 23.0 0.9 3
045460.0080 6.0 3.0 43.0 33.0 1.0 3
045460.0090 6.0 3.0 53.0 43.0 1.0 3
045480 Sensor insert NÜSSLER
Carbide shank, Ø 1.0 mm, ruby ball / type F
Order ID dk d1 L ML Weight ds
mm mm mm mm g mm
045480.0010 0.25 0.2 15.3 2.5 0.2 1.0
045480.0020 0.30 0.2 15.3 2.5 0.2 1.0
045480.0030 0.4 0.3 15.4 2.5 0.2 1.0
045480.0040 0.5 0.3 15.5 2.5 0.2 1.0
045480.0050 0.6 0.4 15.6 4.5 0.3 1.0
045480.0060 0.7 0.4 15.7 4.5 0.3 1.0
045480.0070 0.8 0.6 15.8 4.5 0.3 1.0
045480.0080 0.9 0.6 15.9 4.5 0.3 1.0
045480.0090 1.0 0.8 16.0 4.5 0.4 1.0
045485 Sensor insert NÜSSLER
Carbide shank, Ø 1.0 mm, ruby ball / type N
Order ID dk ds L Weight
mm mm mm g
045485.0010 1.35 1.0 26.4 0.3
045485.0020 1.50 1.0 26.5 0.3
045485.0030 2.00 1.0 26.0 0.3
045485.0040 2.0 1.0 45.0 0.5
045485.0050 2.0 1.0 61.0 0.7
045485.0060 2.0 1.0 81.0 1.0

Brütsch/Rüegger Tools Ltd. • Heinrich Stutz-Strasse 20 • P.O. Box • CH-8902 Urdorf • www.brw.ch 211
