Drilling with inserts Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 56405 Indexable insert drill ISCAR SUMOCHAM 3xD

3xD

Drilling depths 3 x D, Type DCN A/R-3D,cylindrical shank with flat, internal cooling.
Important: Do not use any interchangeable heads smaller than the D range specified for the
drill body.
Corresponding inserts:
156490 Interchangeable head drill ISCAR CHAMDRILL
Package content: with key, but without interchangeable drilling head.
Order ID D L for area D Drill head d d1 L1 L2 Spanners
mm mm mm mm mm mm mm
156405.0100 8 24 8.0...8.4 8 12 16 39.4 45 K DCN 6-9.99
156405.0200 8.5 25 8.5...8.9 8 12 16 40.9 45 K DCN 6-9.99
156405.0300 9 27 9.0...9.4 9 12 16 42.8 45 K DCN 6-9.99
156405.0400 9.5 29 9.5...9.9 9 12 16 44.3 45 K DCN 6-9.99
156405.0500 10 30 10.0...10.4 10 16 20 46.2 48 K DCN 10-13.99
156405.0600 10.5 32 10.5...10.9 10 16 20 47.07 48 K DCN 10-13.99
156405.0700 11 33 11.0...11.4 11 16 20 49.6 48 K DCN 10-13.99
156405.0800 11.5 35 11.5...11.9 11 16 20 51.1 48 K DCN 10-13.99
156405.0900 12 36 12.0...12.4 12 16 20 53 48 K DCN 10-13.99
156405.1000 12.5 37 12.5...12.9 12 16 20 54.5 48 K DCN 10-13.99
156405.1100 13 39 13.0...13.4 13 16 20 56.6 48 K DCN 10-13.99
156405.1200 13.5 41 13.5...13.9 13 16 20 58.1 48 K DCN 10-13.99
156405.1300 14 42 14.0...14.4 14 16 20 62.1 48 K DCN 14-17.99
156405.1400 14.5 44 14.5...14.9 14 16 20 63.6 48 K DCN 14-17.99
156405.1500 15 45 15.0...15.9 15 20 25 68.7 50 K DCN 14-17.99
156405.1600 16 48 16.0...16.9 16 20 25 73.3 50 K DCN 14-17.99
156405.1700 17 51 17.0...17.9 17 20 25 77.9 50 K DCN 14-17.99
156405.1800 18 54 18.0...18.9 18 25 32 82.5 56 K DCN 18-21.99
156405.1900 19 57 19.0...19.9 19 25 32 87 56 K DCN 18-21.99
156405.2000 20 60 20.0...20.9 20 25 32 91.6 56 K DCN 18-21.99
156405.2100 21 63 21.0...21.9 21 25 32 96.2 56 K DCN 18-21.99
156405.2200 22 66 22.0...22.9 22 25 32 100.8 56 K DCN 22-26.99
156405.2300 23 69 23.0...23.9 23 32 42 105.4 60 K DCN 22-26.99
156405.2400 24 72 24.0...24.9 24 32 42 110 60 K DCN 22-26.99
156405.2500 25 75 25.0...25.9 25 32 42 114.5 60 K DCN 22-26.99
1 56455 Indexable insert drill ISCAR SUMOCHAM 5XD

5xD

Drilling depths 5 x D, Type DCN A/R-5D, cylindrical shank with flat, internal cooling.
Important: Do not use interchangeable heads, that are smaller than the range D defined for
the drilling head carrier.
Corresponding inserts:
156490 Interchangeable head drill ISCAR CHAMDRILL
Package content: with key, but without interchangeable drilling head.
Order ID D L for area D Drill head d d1 L1 L2 Spanners
mm mm mm mm mm mm mm
156455.0100 8 40 8.0...8.4 8 12 16 55.4 45 K DCN 6-9.99
156455.0200 8.5 42 8.5...8.9 8 12 16 57.9 45 K DCN 6-9.99
156455.0300 9 45 9.0...9.4 9 12 16 60.8 45 K DCN 6-9.99
156455.0400 9.5 48 9.5...9.9 9 12 16 63.3 45 K DCN 6-9.99
156455.0500 10 50 10.0...10.4 10 16 20 66.2 48 K DCN 10-13.99
156455.0600 10.5 53 10.5...10.9 10 16 20 68.7 48 K DCN 10-13.99
156455.0700 11 55 11.0...11.4 11 16 20 71.6 48 K DCN 10-13.99
156455.0800 11.5 58 11.5...11.9 11 16 20 74.1 48 K DCN 10-13.99
156455.0900 12 60 12.0...12.4 12 16 20 77 48 K DCN 10-13.99
156455.1000 12.5 62 12.5...12.9 12 16 20 79.5 48 K DCN 10-13.99
156455.1100 13 65 13.0...13.4 13 16 20 82.6 48 K DCN 10-13.99
156455.1200 13.5 68 13.5...13.9 13 16 20 85.1 48 K DCN 10-13.99
156455.1300 14 70 14.0...14.4 14 16 20 90.15 48 K DCN 14-17.99
156455.1400 14.5 73 14.5...14.9 14 16 20 92.65 48 K DCN 14-17.99
156455.1500 15 75 15.0...15.9 15 20 25 98.73 50 K DCN 14-17.99
156455.1600 16 80 16.0...16.9 16 20 25 105.3 50 K DCN 14-17.99
156455.1700 17 85 17.0...17.9 17 20 25 111.9 50 K DCN 14-17.99
156455.1800 18 90 18.0...18.9 18 25 32 118.5 56 K DCN 18-21.99
156455.1900 19 95 19.0...19.9 19 25 32 125 56 K DCN 18-21.99
156455.2000 20 100 20.0...20.9 20 25 32 131.6 56 K DCN 18-21.99
156455.2100 21 105 21.0...21.9 21 25 32 138.2 56 K DCN 18-21.99
156455.2200 22 110 22.0...22.9 22 25 32 144.8 56 K DCN 22-26.99
156455.2300 23 115 23.0...23.9 23 32 42 151.4 60 K DCN 22-26.99
156455.2400 24 120 24.0...24.9 24 32 42 158 60 K DCN 22-26.99
156455.2500 25 125 25.0...25.9 25 32 42 164.5 60 K DCN 22-26.99
