Drilling with inserts Tel. +41 44 736 63 63 • Fax +41 44 736 63 00 • sales@brw.ch
1 56490 Interchangeable head drill ISCAR CHAMDRILL

P M

Type IC, carbide IC 908, TiAlN coating.
Fields of application: steel (ICP), stainless steel (ICM).
Appropriate tool holders:
156405 Indexable insert drill ISCAR SUMOCHAM 3xD
156455 Indexable insert drill ISCAR SUMOCHAM 5XD
156460 Indexable insert drill ISCAR SUMOCHAM 8xD
Order ID d s Type Order ID d s Type Order ID d s Type
mm mm mm mm mm mm
156490.0010 8 5.4 ICP 156490.1640 13.4 7.6 ICM 156490.3270 19 11 ICP
156490.0020 8 5.4 ICM 156490.1660 13.5 7.6 ICP 156490.3280 19 11 ICM
156490.0040 8.1 5.4 ICP 156490.1670 13.5 7.6 ICM 156490.3300 19.05 11 ICP
156490.0050 8.1 5.4 ICM 156490.1690 13.6 7.6 ICP 156490.3310 19.05 11 ICM
156490.0070 8.2 5.4 ICP 156490.1700 13.6 7.6 ICM 156490.3330 19.1 11 ICP
156490.0080 8.2 5.4 ICM 156490.1720 13.7 7.6 ICP 156490.3340 19.1 11 ICM
156490.0100 8.3 5.4 ICP 156490.1730 13.7 7.6 ICM 156490.3360 19.2 11 ICP
156490.0110 8.3 5.4 ICM 156490.1750 13.8 7.6 ICP 156490.3370 19.2 11 ICM
156490.0130 8.4 5.4 ICP 156490.1760 13.8 7.6 ICM 156490.3390 19.3 11 ICP
156490.0140 8.4 5.4 ICM 156490.1780 13.9 7.6 ICP 156490.3400 19.3 11 ICM
156490.0160 8.5 5.4 ICP 156490.1790 13.9 7.6 ICM 156490.3420 19.4 11 ICP
156490.0170 8.5 5.4 ICM 156490.1810 14 8.15 ICP 156490.3430 19.4 11 ICM
156490.0190 8.6 5.4 ICP 156490.1820 14 8.15 ICM 156490.3450 19.5 11 ICP
156490.0200 8.6 5.4 ICM 156490.1840 14.1 8.15 ICP 156490.3460 19.5 11 ICM
156490.0220 8.7 5.4 ICP 156490.1850 14.1 8.15 ICM 156490.3480 19.6 11 ICP
156490.0230 8.7 5.4 ICM 156490.1870 14.2 8.15 ICP 156490.3490 19.6 11 ICM
156490.0250 8.8 5.4 ICP 156490.1880 14.2 8.15 ICM 156490.3510 19.7 11 ICP
156490.0260 8.8 5.4 ICM 156490.1900 14.3 8.15 ICP 156490.3520 19.7 11 ICM
156490.0280 8.9 5.4 ICP 156490.1910 14.3 8.15 ICM 156490.3540 19.8 11 ICP
156490.0290 8.9 5.4 ICM 156490.1930 14.4 8.15 ICP 156490.3550 19.8 11 ICM
156490.0310 9 5.8 ICP 156490.1940 14.4 8.15 ICM 156490.3570 19.9 11 ICP
156490.0320 9 5.8 ICM 156490.1960 14.5 8.15 ICP 156490.3580 19.9 11 ICM
156490.0340 9.1 5.8 ICP 156490.1970 14.5 8.15 ICM 156490.3600 20 11.6 ICP
156490.0350 9.1 5.8 ICM 156490.1990 14.6 8.15 ICP 156490.3610 20 11.6 ICM
156490.0370 9.2 5.8 ICP 156490.2000 14.6 8.15 ICM 156490.3630 20.1 11.6 ICP
156490.0380 9.2 5.8 ICM 156490.2020 14.7 8.15 ICP 156490.3640 20.1 11.6 ICM
156490.0400 9.3 5.8 ICP 156490.2030 14.7 8.15 ICM 156490.3660 20.2 11.6 ICP
156490.0410 9.3 5.8 ICM 156490.2050 14.8 8.15 ICP 156490.3670 20.2 11.6 ICM
156490.0430 9.4 5.8 ICP 156490.2060 14.8 8.15 ICM 156490.3690 20.3 11.6 ICP
156490.0440 9.4 5.8 ICM 156490.2080 14.9 8.15 ICP 156490.3700 20.3 11.6 ICM
156490.0460 9.5 5.8 ICP 156490.2090 14.9 8.15 ICM 156490.3720 20.4 11.6 ICP
156490.0470 9.5 5.8 ICM 156490.2110 15 8.73 ICP 156490.3730 20.4 11.6 ICM
156490.0490 9.6 5.8 ICP 156490.2120 15 8.73 ICM 156490.3750 20.5 11.6 ICP
156490.0500 9.6 5.8 ICM 156490.2140 15.1 8.73 ICP 156490.3760 20.5 11.6 ICM
156490.0520 9.7 5.8 ICP 156490.2150 15.1 8.73 ICM 156490.3780 20.6 11.6 ICP
156490.0530 9.7 5.8 ICM 156490.2170 15.2 8.73 ICP 156490.3790 20.6 11.6 ICM
156490.0550 9.8 5.8 ICP 156490.2180 15.2 8.73 ICM 156490.3810 20.7 11.6 ICP
156490.0560 9.8 5.8 ICM 156490.2200 15.3 8.73 ICP 156490.3820 20.7 11.6 ICM
156490.0580 9.9 5.8 ICP 156490.2210 15.3 8.73 ICM 156490.3840 20.8 11.6 ICP
156490.0590 9.9 5.8 ICM 156490.2230 15.4 8.73 ICP 156490.3850 20.8 11.6 ICM
156490.0610 10 6.2 ICP 156490.2240 15.4 8.73 ICM 156490.3870 20.9 11.6 ICP
156490.0620 10 6.2 ICM 156490.2260 15.5 8.73 ICP 156490.3880 20.9 11.6 ICM
156490.0640 10.1 6.2 ICP 156490.2270 15.5 8.73 ICM 156490.3900 21 12.2 ICP
156490.0650 10.1 6.2 ICM 156490.2290 15.6 8.73 ICP 156490.3910 21 12.2 ICM
156490.0670 10.2 6.2 ICP 156490.2300 15.6 8.73 ICM 156490.3930 21.1 12.2 ICP
156490.0680 10.2 6.2 ICM 156490.2320 15.7 8.73 ICP 156490.3940 21.1 12.2 ICM
156490.0700 10.3 6.2 ICP 156490.2330 15.7 8.73 ICM 156490.3960 21.2 12.2 ICP
156490.0710 10.3 6.2 ICM 156490.2350 15.8 8.73 ICP 156490.3970 21.3 12.2 ICP
156490.0730 10.4 6.2 ICP 156490.2360 15.8 8.73 ICM 156490.3980 21.4 12.2 ICP
156490.0740 10.4 6.2 ICM 156490.2380 15.9 8.73 ICP 156490.3990 21.5 12.2 ICP
156490.0760 10.5 6.2 ICP 156490.2390 15.9 8.73 ICM 156490.4000 21.5 12.2 ICM
156490.0770 10.5 6.2 ICM 156490.2410 16 9.3 ICP 156490.4020 21.6 12.2 ICP
156490.0790 10.6 6.2 ICP 156490.2420 16 9.3 ICM 156490.4030 21.7 12.2 ICP
156490.0800 10.6 6.2 ICM 156490.2440 16.1 9.3 ICP 156490.4040 21.8 12.2 ICP
156490.0820 10.7 6.2 ICP 156490.2450 16.1 9.3 ICM 156490.4050 21.9 12.2 ICP
156490.0830 10.7 6.2 ICM 156490.2470 16.2 9.3 ICP 156490.4060 22 12.8 ICP
156490.0850 10.8 6.2 ICP 156490.2480 16.2 9.3 ICM 156490.4070 22 12.8 ICM
156490.0860 10.8 6.2 ICM 156490.2500 16.3 9.3 ICP 156490.4090 22.1 12.8 ICP
156490.0880 10.9 6.2 ICP 156490.2510 16.3 9.3 ICM 156490.4100 22.1 12.8 ICM
156490.0890 10.9 6.2 ICM 156490.2530 16.4 9.3 ICP 156490.4120 22.2 12.8 ICP
156490.0910 11 6.6 ICP 156490.2540 16.4 9.3 ICM 156490.4130 22.2 12.8 ICM
156490.0920 11 6.6 ICM 156490.2560 16.5 9.3 ICP 156490.4150 22.3 12.8 ICP
156490.0940 11.1 6.6 ICP 156490.2570 16.5 9.3 ICM 156490.4160 22.4 12.8 ICP
156490.0950 11.1 6.6 ICM 156490.2590 16.6 9.3 ICP 156490.4170 22.5 12.8 ICP
156490.0970 11.2 6.6 ICP 156490.2600 16.6 9.3 ICM 156490.4180 22.5 12.8 ICM
156490.0980 11.2 6.6 ICM 156490.2620 16.7 9.3 ICP 156490.4200 22.6 12.8 ICP
156490.1000 11.3 6.6 ICP 156490.2630 16.7 9.3 ICM 156490.4210 22.6 12.8 ICM
156490.1010 11.3 6.6 ICM 156490.2650 16.8 9.3 ICP 156490.4230 22.7 12.8 ICP
156490.1030 11.4 6.6 ICP 156490.2660 16.8 9.3 ICM 156490.4240 22.7 12.8 ICM
156490.1040 11.4 6.6 ICM 156490.2680 16.9 9.3 ICP 156490.4260 22.8 12.8 ICP
156490.1060 11.5 6.6 ICP 156490.2690 16.9 9.3 ICM 156490.4270 22.9 12.8 ICP
